Additional printer setup
In Windows 8
From the Search charm, type run, and then navigate to:
Apps list > Run > type control printers > OK
In Windows 7 or earlier
a
Click or click Start, and then click Run.
b
In the Start Search or Run dialog, type control printers.
c
Press Enter, or click OK.
2
Depending on your device, do either of the following:
• Press and hold the printer you want to update.
•
Right‑click the printer you want to update.
3
From the menu that appears, do either of the following:
•
For Windows 7 or later, select Printer properties.
• For earlier versions, select Properties.
4
Click the Configuration tab.
5
Do either of the following:
Click Update Now ‑ Ask Printer.
•
•
Under Configuration Options, manually add any installed hardware options.
6
Click Apply.
For Macintosh users
1
From the Apple menu, navigate to either of the following:
•
System Preferences > Print & Scan > select your printer > Options & Supplies > Driver
•
System Preferences > Print & Fax > select your printer > Options & Supplies > Driver
2
Add any installed hardware options, and then click OK.

Networking

Note: A Service Set Identifier (SSID) is a name assigned to a wireless network. Wired Equivalent Privacy (WEP), Wi-Fi
Protected Access (WPA), WPA2, and 802.1X - RADIUS are types of security used on a network.

Preparing to set up the printer on an Ethernet network

To configure your printer to connect to an Ethernet network, organize the following information before you begin:
Note: If your network automatically assigns IP addresses to computers and printers, continue on to installing the
printer.
•
A valid, unique IP address for the printer to use on the network
•
The network gateway
35
