Additional printer setup

Installing optional drawers

CAUTION—POTENTIAL INJURY: The printer weight is greater than 18 kg (40 lb) and requires two or more
trained personnel to lift it safely.
CAUTION—POTENTIAL INJURY: If you are accessing the system board or installing optional hardware or
memory devices sometime after setting up the printer, then turn the printer off, and unplug the power cord
from the wall outlet before continuing. If you have any other devices attached to the printer, then turn them off
as well, and unplug any cables going into the printer.
CAUTION—TIPPING HAZARD: Floor-mounted configurations require additional furniture for stability. You must
use either a printer stand or printer base if you are using a high-capacity input tray, a duplex unit and an input
option, or more than one input option. If you purchased a multifunction printer (MFP) that scans, copies, and
faxes, you may need additional furniture. For more information, see www.lexmark.com/multifunctionprinters.
1
Unpack the optional drawer, and then remove all packing material.
Note: Optional drawers lock together when stacked. Remove stacked drawers one at a time from the top to the
bottom.
2
Place the drawer near the printer.
3
Turn off the printer.
4
Align the printer with the drawer, and then lower the printer into place.
1 Optional 550‑sheet specialty media drawer
2 Optional 550‑sheet drawer
1
2
3
