CMA Dishmachines CWS Parts Manual

Hide thumbs Also See for CWS:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service & Parts Manual
MODEL CWS
PARTS MANUAL
Rev.1.00
C M A
D I S H M A C H I N E S
1 2 7 0 0 K N O T T A V E N U E
GARDEN GROVE, CALIFORNIA 92841
8 0 0 - 8 5 4 - 6 4 1 7
F A X 7 1 4 - 8 9 5 - 2 1 4 1
www.cmadishmachines.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CWS and is the answer not in the manual?

Questions and answers

Related Manuals for CMA Dishmachines CWS

Summary of Contents for CMA Dishmachines CWS

  • Page 1 MODEL CWS PARTS MANUAL Rev.1.00 C M A D I S H M A C H I N E S 1 2 7 0 0 K N O T T A V E N U E GARDEN GROVE, CALIFORNIA 92841...

  • Page 2: Table Of Contents

    ABLE OF ONTENTS ODEL PARTS MANUAL ..................3 1.1. (P/N)......................... 3 NITIAL ARTS 1.2........................4 PTIONAL LARM 1.3......................5 XPLODED RAWINGS 1.3.1. Cabinet Assembly ........................5 1.3.2. Three Compartment Sink ......................6 1.3.3. Control Box Assembly ......................7 1.3.4. Door Actuator Assembly......................

  • Page 3: Parts Manual

    00715.00 1/2” Boll Check Valve 00735.00 3/4” Vac. Breaker Repair Kit Watts 13003.50 Contactor 60 Amp 3 Pole 13003.50 Contactor 30 Amp 13415.00 EGO Thermostat Retrofit Kit 17523.51 Hi Limit Switch 250 Deg. Page MODEL CWS PARTS MANUAL Rev. 1.00...

  • Page 4: Optional Sani Alarm

    00435.00 Squeeze Tube, 8” 40126.10 #10 x 3/4" Sheet metal Screw 00521.00 Wire, 18 Gauge, Orange, 6 ft. 40127.00 Wall Anchors 00531.00 Wire, 18 Gauge, White, 6 ft. 00426.00 Y Hose Connector, 3/16” Page MODEL CWS PARTS MANUAL Rev. 1.00...

  • Page 5: Exploded View Drawings

    ¼”-20x5/8” Hex Head Bolt 16904.00 CWS Chemical Tray 00911.00 8-32x1/2 » Pan Head Screw 01554.50 EZ Glide Door Guide ss.33” 01577.40 Scrap Trap Lid 16920.50 CWS Pan /Stand Right Sink 00115.85 Drain Screen VA Page MODEL CWS PARTS MANUAL Rev. 1.00...

  • Page 6: Three Compartment Sink

    Bullet foot 20420.00 Pre Rinse Hose Pipe Adapter 20505.00 CWS ½” Faucet 20415.00 Pre Rinse Wall Bracket 20411.00 Pre Rinse Unit 20418.00 Pre Rinse Riser Pipe 20414.00 Pre Rinse Brush 20413.00 Add On Faucet Page MODEL CWS PARTS MANUAL Rev. 1.00...

  • Page 7: Control Box Assembly

    13003.17 Main Contactor 60 Amp 03408.55 Counter (Panel Mount) 220 V 00408.40 Timer 120 Sec 8 Cam 220V/60Hz 16903.00 Control Box Body 01514.00 Timer Support Bar 00470.10 Toggle Switch Rubber Boot 00411.00 Microswitch Page MODEL CWS PARTS MANUAL Rev. 1.00...

  • Page 8: Door Actuator Assembly

    00606.00 5/16-18 x 7” Eyebolt 01555.50 Door Handle Support, 1” (Left) 00913.00 5/16-18 Nut 00903.00 1/4-20 x 1-3/4” Hex Head Screw 00926.00 5/16” SS Washer 00607.04 Door Handle Cap, 1” 00900.00 Cotter Pin Page MODEL CWS PARTS MANUAL Rev. 1.00...

  • Page 9: Pump Assembly

    Pump Cover 00921.00 3/8 “ –16 X 3/4” Hex Head Bolt 50302.40 1-1/4” MIP X 1” Barb Fitting 00926.00 5/16” SS Washer 50302.06 1” MPT X 1” Barb Fitting 00200.14 CWS Pump Motor Assembly Page MODEL CWS PARTS MANUAL Rev. 1.00...

  • Page 10: Plumbing System Assembly

    00795.60 Flush Tube CWS 00716.00 1/2 “ X 1/2” X 3/4” Tee F X F X F 00912.00 1/4”-20 Nylon Lock Nut 00721.00 1/2 “ Jamb Nut Thin Pattern 00922.00 1/4” Lock Nut Page MODEL CWS PARTS MANUAL Rev. 1.00...

  • Page 11: Spray System Assembly

    Spray Base Lock Pin 00304.06 Spray Arm 00363.10 Lock Pin Spring 00308.50 Spray Arm End Plug 50302.06 1" MPT X 1" Barb Fitting 00305.65 CWS Manifold 00302.84 Spray Base 0-Ring 04306.00 Square Manifold Gasket Page MODEL CWS PARTS MANUAL Rev. 1.00...

  • Page 12: Power Drain Assembly

    00121.60 Drain Diaphragm 00109.82 Drain Actuator Shaft (V) 00912.00 1/4-20 Nylon Lock Nut 00104.86 50 RPM Drain Motor, 220V 60Hz 01521.82 Diaphragm Support Disk, 2” 00109.40 Shoulder Nut, SS 04806.00 #10 Brass Washer Page MODEL CWS PARTS MANUAL Rev. 1.00...

  • Page 13: Peristaltic Pump Assembly

    8-32 x 1/2" Pan Head Screw 00425.53 Chemical Tubing, Red 00435.00 Squeeze Tube 00425.54 Chemical Tubing, White 00419.00 2-Bearing Rotor Assembly 00443.00 Tube Stiffener 03426.00 Sight Glass 90 Deg Elbow 00435.11 Squeeze Tube 3” 00932.00 Twist tye Page MODEL CWS PARTS MANUAL Rev. 1.00...

  • Page 14: Booster Heater Assembly

    1/2” Male Plug Brass 00941.00 10-32” X 5/8 “ Pan Head Screw 17523.51 Hi Limit Switch 250 Deg. 00971.10 4-40 Nylon Lock Nut 41030.10 ½” 90 Deg. Ell. FXF Brass 01594.10 Booster Tank Access Cover Page MODEL CWS PARTS MANUAL Rev. 1.00...
