MODEL CWS
SERVICE & PARTS MANUAL
C M A
D I S H M A C H I N E S
1 2 7 0 0 K N O T T A V E N U E
GARDEN GROVE, CALIFORNIA 92841
8 0 0 - 8 5 4 - 6 4 1 7
F A X 7 1 4 - 8 9 5 - 2 1 4 1
www.cmadishmachines.com
Rev 1.00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CWS and is the answer not in the manual?

Questions and answers

Summary of Contents for CMA Dishmachines CWS

  • Page 1 MODEL CWS SERVICE & PARTS MANUAL Rev 1.00 C M A D I S H M A C H I N E S 1 2 7 0 0 K N O T T A V E N U E GARDEN GROVE, CALIFORNIA 92841...
  • Page 2: Table Of Contents

    ABLE OF ONTENTS Model CWS SPECIFICATIONS ..................2 CWS ............................... 2 2. GETTING STARTED ..................3 2.1. CWS ......................3 NTRODUCTION TO THE 2.2....................... 4 ECEIVING AND NSTALLATION 2.2.1. Electrical ..........................4 2.2.2. Plumbing..........................4 2.2.3. Connecting the Scrap Accumulator and Drain............... 5 3.
  • Page 3: Model Cws

    19 ¾” x 19 ¾” (50 x 50 cm) VOLTS ELECTRICAL RATING AMPS (60-Hz) SINGLE PHASE SINGLE PHASE THREE PHASE THREE PHASE WASH PUMP MOTOR 2 HP SHIPPING WEIGHT APPROXIMATE 708# (321 kg) Page MODEL CWS SERVICE & PARTS MANUAL Rev. 1.00...
  • Page 4: Getting Started

    2.1. Introduction to the CWS The CWS Dishmachine is safe and easy to operate with its “Auto Start/Stop” and it’s economical to operate—using only 1.7gallons of water per cycle. The CWS Dishmachine’s top mounted controls include built-in chemical pumps and a de-liming system that assures proper chemical usage.
  • Page 5: Receiving And Installation

    Be careful not to remove any of the tie-wraps securing the tube bundle. Red is for detergent, white for sanitizer, and blue for rinse aid. 2.2.1. Electrical The CWS Dishmachine must be hard wired directly to a dedicated 240 VAC, 60Hz, 3 Phase. circuit equipped with proper circuit protection. 2.2.2. Plumbing The water supply connection is made with a ¾”...
  • Page 6: Connecting The Scrap Accumulator And Drain

    The drainpipe is connected to the scrap accumulator drain using a 2” no-hub connector as shown below. Figure 2.2.3 SCRAP ACCUMULATOR 2" DRAIN 2" 2" DRAINPIPE SLEEVE NO-HUB HOSE CLAMPS Figure 2.2.3 Page MODEL CWS SERVICE & PARTS MANUAL Rev. 1.00...
  • Page 7: Operation

    If a peristaltic pump does not turn when the micro switch is activated, loosen the screws on the cover plate. Technical personnel are available during normal business hours at CMA Headquarters should you, as an installer, have any questions please call 800-854-6417. Page MODEL CWS SERVICE & PARTS MANUAL Rev. 1.00...
  • Page 8: Startup Procedures

    7. After the machine stops, raise the doors, remove the tray of dishes and allow to dry before stacking. If the doors are lifted during a cycle, the machine will automatically stop running. The CWS will run through the wash and rinse cycles automatically feeding the proper chemicals and then turn itself off. Page...
  • Page 9: Parts Manual

    1/2” Boll Check Valve 00735.00 3/4” Vac. Breaker Repair Kit Watts 13003.50 Contactor 60 Amp 3 Pole 13003.50 Contactor 30 Amp 13415.00 EGO Thermostat Retrofit Kit 17523.51 Hi Limit Switch 250 Deg. Page MODEL CWS SERVICE & PARTS MANUAL Rev. 1.00...
  • Page 10: Optional Sani Alarm

    Squeeze Tube, 8” 40126.10 #10 x 3/4" Sheet metal Screw 00521.00 Wire, 18 Gauge, Orange, 6 ft. 40127.00 Wall Anchors 00531.00 Wire, 18 Gauge, White, 6 ft. 00426.00 Y Hose Connector, 3/16” Page MODEL CWS SERVICE & PARTS MANUAL Rev. 1.00...
  • Page 11: Exploded View Drawings

    ¼”-20x5/8” Hex Head Bolt 16904.00 CWS Chemical Tray 00911.00 8-32x1/2 » Pan Head Screw 01554.50 EZ Glide Door Guide ss.33” 01577.40 Scrap Trap Lid 16920.50 CWS Pan /Stand Right Sink 00115.85 Drain Screen VA Page MODEL CWS SERVICE & PARTS MANUAL Rev. 1.00...
  • Page 12: Three Compartment Sink

    Pre Rinse Hose Pipe Adapter 20505.00 CWS ½” Faucet 20415.00 Pre Rinse Wall Bracket 20411.00 Pre Rinse Unit 20418.00 Pre Rinse Riser Pipe 20414.00 Pre Rinse Brush 20413.00 Add On Faucet Page MODEL CWS SERVICE & PARTS MANUAL Rev. 1.00...
  • Page 13: Control Box Assembly

    Main Contactor 60 Amp 03408.55 Counter (Panel Mount) 220 V 00408.40 Timer 120 Sec 8 Cam 220V/60Hz 16903.00 Control Box Body 01514.00 Timer Support Bar 00470.10 Toggle Switch Rubber Boot 00411.00 Microswitch Page MODEL CWS SERVICE & PARTS MANUAL Rev. 1.00...
  • Page 14: Door Actuator Assembly

    5/16-18 x 7” Eyebolt 01555.50 Door Handle Support, 1” (Left) 00913.00 5/16-18 Nut 00903.00 1/4-20 x 1-3/4” Hex Head Screw 00926.00 5/16” SS Washer 00607.04 Door Handle Cap, 1” 00900.00 Cotter Pin Page MODEL CWS SERVICE & PARTS MANUAL Rev. 1.00...
  • Page 15: Pump Assembly

    3/8 “ –16 X 3/4” Hex Head Bolt 50302.40 1-1/4” MIP X 1” Barb Fitting 00926.00 5/16” SS Washer 50302.06 1” MPT X 1” Barb Fitting 00200.14 CWS Pump Motor Assembly Page MODEL CWS SERVICE & PARTS MANUAL Rev. 1.00...
  • Page 16: Plumbing System Assembly

    Flush Tube CWS 00716.00 1/2 “ X 1/2” X 3/4” Tee F X F X F 00912.00 1/4”-20 Nylon Lock Nut 00721.00 1/2 “ Jamb Nut Thin Pattern 00922.00 1/4” Lock Nut Page MODEL CWS SERVICE & PARTS MANUAL Rev. 1.00...
  • Page 17: Spray System Assembly

    Spray Base Lock Pin 00304.06 Spray Arm 00363.10 Lock Pin Spring 00308.50 Spray Arm End Plug 50302.06 1" MPT X 1" Barb Fitting 00305.65 CWS Manifold 00302.84 Spray Base 0-Ring 04306.00 Square Manifold Gasket Page MODEL CWS SERVICE & PARTS MANUAL Rev. 1.00...
  • Page 18: Power Drain Assembly

    Drain Diaphragm 00109.82 Drain Actuator Shaft (V) 00912.00 1/4-20 Nylon Lock Nut 00104.86 50 RPM Drain Motor, 220V 60Hz 01521.82 Diaphragm Support Disk, 2” 00109.40 Shoulder Nut, SS 04806.00 #10 Brass Washer Page MODEL CWS SERVICE & PARTS MANUAL Rev. 1.00...
  • Page 19: Power Drain Retrofit Kit

    Parts Manual 4.3.9. Power Drain Retrofit Kit Page MODEL CWS SERVICE & PARTS MANUAL Rev. 1.00...
  • Page 20: Peristaltic Pump Assembly

    00425.53 Chemical Tubing, Red 00435.00 Squeeze Tube 00425.54 Chemical Tubing, White 00419.00 2-Bearing Rotor Assembly 00443.00 Tube Stiffener 03426.00 Sight Glass 90 Deg Elbow 00435.11 Squeeze Tube 3” 00932.00 Twist tye Page MODEL CWS SERVICE & PARTS MANUAL Rev. 1.00...
  • Page 21: Booster Heater Assembly

    00941.00 10-32” X 5/8 “ Pan Head Screw 17523.51 Hi Limit Switch 250 Deg. 00971.10 4-40 Nylon Lock Nut 41030.10 ½” 90 Deg. Ell. FXF Brass 01594.10 Booster Tank Access Cover Page MODEL CWS SERVICE & PARTS MANUAL Rev. 1.00...
  • Page 22: Electrical Diagram

    Electrical Diagram 5. Electrical Diagram Page MODEL CWS SERVICE & PARTS MANUAL Rev. 1.00...
