BiPAC 7300(N)
802.11n ADSL2+ Firewall Router

User Manual

Version Released: 1.14 (FW: 1.07)
Last Revised on 3-10-2010

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BiPAC 7300N and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Billion BiPAC 7300N

Summary of Contents for Billion BiPAC 7300N

  • Page 1: User Manual

    BiPAC 7300(N) 802.11n ADSL2+ Firewall Router User Manual Version Released: 1.14 (FW: 1.07) Last Revised on 3-10-2010...

  • Page 2: Table Of Contents

    Table of Contents Chapter 1 ....................1 1.1 Introducing the BiPAC 7300(N) ..........1 1.2 Features................. 3 1.3 Applications of the BiPAC 7300(N) ........6 Chapter 2 ....................7 2.1 Important Notes ..............8 2.2 Package Contents ..............8 2.3 The Front LEDs ..............9 2.4 The Rear Ports ..............
  • Page 3 5.4 Save Configuration to Flash ..........125 5.5 Restart ................125 5.6 Logout................126 Chapter 6 ..................... 127...

  • Page 4: Chapter 1

    Chapter 1 Introduction 1.1 Introducing the BiPAC 7300(N) Thank you for purchasing the BiPAC 7300(N) Router. Your new router is an all-in-one unit that combines an ADSL modem, ADSL2/2+ router and Ethernet network switch to provide everything you need to get the machines on your network connected to the Internet over an ADSL broadband connection.
  • Page 5 The BiPAC 7300(N) provides two levels of security support. First, it masks LAN IP addresses making them invisible to outside users on the Internet, so it is much more difficult for a hacker to target a machine on your network. Second, it can block and redirect certain ports to limit the services that outside users can access.

  • Page 6: Features

    1.2 Features Express Internet Access – ADSL2/2+ capable The BiPAC 7300(N) complies with ADSL worldwide standards. Supporting downstream rates of 8 Mbps with ADSL, the router is capable of up to 12/24 Mbps with ADSL2/2+, and upstream rates of up to 3 Mbps. Users enjoy not only high-speed ADSL services but also broadband multimedia applications such as interactive gaming, video streaming and real-time audio which are easier and faster than ever.
  • Page 7 Universal Plug and Play (UPnP) and UPnP NAT Traversal This protocol is used to enable simple and robust connectivity among stand-alone devices and PCs from many different vendors, and it makes setting up a network simple and affordable. UPnP architecture leverages TCP/IP and the Web to enable proximity networking in addition to control and data transfer among networked devices.
  • Page 8 QoS gives you full control over which types of outgoing data traffic should be given priority by the router, ensuring important data like gaming packets, customer information, or management information move through the router ay lightning speed, even under heavy load.

  • Page 9: Applications Of The Bipac 7300(N)

    1.3 Applications of the BiPAC 7300(N)

  • Page 10: Chapter 2

    Chapter 2 Product Overview Standards-Based Technology The BiPAC 7300(N) Wireless Router utilizes the 802.11n standard. The IEEE 802.11n standard is an extension of the 802.11g standard. It increases the data rate up to 300 Mbps within the 2.4GHz band, utilizing OFDM technology. This means that in most environments, within the specified range of this device, you will be able to transfer large files quickly or even watch a movie in MPEG format over your network without noticeable delays.

  • Page 11: Important Notes

    2.1 Important Notes Do not use the BiPAC 7300(N) in high humidity or high temperatures. Do not use the same power source for the BiPAC 7300(N) as other equipment. Do not open or repair the case yourself. If the BiPAC 7300(N) is Warning too hot, turn off the power immediately and have it repaired at a qualified service center.

  • Page 12: The Front Leds

    2.3 The Front LEDs Meaning Lit red when WAN port fails to get IP address. Internet Lit green when WAN port gets IP address successfully. Lit when successfully connected to an ADSL DSLAM (“linesync”). (Only available for Blinking when WPS is in progress. 7300N) Wireless Lit green when the wireless connection is established.

  • Page 13: The Rear Ports

    2.4 The Rear Ports Port Description Power Connect the supplied power adapter to this jack. After the router is powered on, press this reset button using the end of paper clip or other small pointed object to reset the router and to restore it to factory default settings.
  • Page 14 The detail instruction in Reset Button 1. Recovery procedures for non-working routers (e.g. after a failed firmware upgrade flash): Hold the Reset Button on the back of the modem in. Keep this button held in and turn on the modem. Once the lights on the modem have stopped flashing, release the Reset Button. modem's emergency-reflash interface...

  • Page 15: Cabling

    2.5 Cabling One of the most common causes of problems is because of bad cabling or ADSL line(s). Make sure that all connected devices are turned on. On the front of the product is a bank of LEDs. Verify that the LAN Link and ADSL line LEDs are lit. If they are not, verify that you are using the proper cables.

  • Page 16: Chapter 3

    Chapter 3 Installation You can configure the BiPAC 7300(N) router through the convenient and user-friendly interface of a web browser. Most popular operating systems such as Linux and Windows 7/Vista/98/NT/2000/XP/Me include a web browser as a standard application. 3.1 Before Configuration PCs must have a properly installed Ethernet interface which connects to the router directly or through an external repeater hub.
  • Page 17 Network Configuration Configuring a PC in Windows 7 Start. Click Control Panel. Then click on Network and Internet. When the Network and Sharing Center window pops up, select and click on Change adapter settings on the left window panel. Select Local Area Connection, and right click...
  • Page 18 Select Internet Protocol Version 4 (TCP/IPv4) then click Properties. In the TCP/IPv4 properties window, select the Obtain address automatically and Obtain Server address automatically radio buttons. Then click OK to exit the setting. Click OK again in the Local Area Connection Properties window to apply the new configuration.
  • Page 19 Configuring a PC in Windows Vista 1. Go to Start. Click on Network. 2. Then click on Network and Sharing Center at the top bar. 3. When Network Sharing Center window pops up, select and click on Manage network connections left window pane.
  • Page 20 5. Select Internet Protocol Version 4 (TCP/IPv4) then click Properties. 6. In the TCP/IPv4 properties window, select the Obtain an IP address automatically and Obtain DNS Server address automatically radio buttons. Then click OK to exit the setting. 7. Click OK again in the Local Area Connection Properties window to apply...
  • Page 21 Configuring a PC in Windows XP 1. Go to Start / Control Panel (in Classic View). In the Control Panel, double-click on Network Connections 2. Double-click Local Area Connection. 3. In the Local Area Connection Status window, click Properties. 4. Select Internet Protocol (TCP/IP) and click Properties.
  • Page 22 Configuring a PC in Windows 2000 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and Dial-up Connections. 2. Double-click Local Area Connection. 3. In the Local Area Connection Status window click Properties. 4.
  • Page 23 Configuring PC in Windows 98/Me 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and choose the Configuration tab. 2. Select TCP/IP ->NE2000 Compatible, or the name of your Network Interface Card (NIC) in your PC. 3.
  • Page 24 Configuring PC in Windows NT4.0 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and choose the Protocols tab. 2. Select TCP/IP Protocol and click Properties. 3. Select the Obtain an IP address from a DHCP server radio button and click OK.

  • Page 25: Factory Default Settings

    3.2 Factory Default Settings Before configuring the BiPAC 7300(N) router, you need to know the following default settings. Web Interface: (Username and Password) Username: admin Password: admin The default username and password are “admin” and “admin” respectively. If you ever forget the username/password to login to the router, you may press the RESET button up to 6 seconds then release it to restore the factory default settings.

  • Page 26: Lan And Wan Port Addresses

    3.3 LAN and WAN Port Addresses The parameters of LAN and WAN ports are preset at the factory. The default values are shown below. LAN Port WAN Port IP address 192.168.1.254 The PPPoE function is enabled to automatically get Subnet Mask 255.255.255.0 the WAN port configuration from the ISP.

  • Page 27: Configuring With Your Bipac 7300(N)

    3.5 Configuring with your BiPAC 7300(N) 1. To configure this device, you must have IE 5.0 / Netscape 4.5 or above installed 2. You may configure the router for Internet access in two ways: (A) Easy Sign-On (EZSO) (B) Web Configuration Easy Sign On After setting up the router with appropriate cables plugged, proceed to load the internet browser to surf Internet, the EZSO WEB GUI will be popped up and request you to input...
  • Page 28 3. Show Auto scan result - Protocol information. 4. Please enter “Username” and “Password” as supplied by your ISP (Internet Service Provider) and click continue. 5. Wait for the device to be configured. 6. You’ve have completed the WAN port setup and now click “Next to Wireless” to proceed to the wireless configuration.
  • Page 29 8. Save Configuration. 9. Congratulations!! You’ve completed the setup procedure and you are now ready to surf the Internet, enjoy.
  • Page 30 Web Configuration Open your web browser, enter the IP address of your router, which by default is 192.168.1.254, and click “Go”, a user name and password window prompt appears. The default username and password are “admin” and “admin”. Congratulations! You have successfully logged on to your BiPAC 7300(N) Router!

  • Page 31: Chapter 4

    Chapter 4 Basic Configuration Once you have logged on to your BiPAC 7300(N) Router via your web browser, you can begin to set it up according to your requirements. On the configuration homepage, the left navigation pane links you directly to the setup pages, which include: Advanced (Switch to Advanced Configuration mode) Status Quick Start...
  • Page 32 4.1 Status Device Information Model Name: Provide a name for the router for identification purposes. System Up-Time: Records system up-time. Hardware Version: Device version Software Version: Firmware version Port Status Port Status: User can look up to see if they are connected to Ethernet, ADSL, EWAN or Wireless.

  • Page 33: Quick Start

    4.2 Quick Start Set Wireless configuration (Only available for 7300N) WLAN Service: Default setting is set to Enable. ESSID: The ESSID is the unique name of a wireless access point (AP) to be distinguished from another. For security purpose, change to a unique ID name to the AP which is already built-in to the router’s wireless interface.

  • Page 34: Wan

    4.3 WAN VPI/VCI: Enter the VPI and VCI information provided by your ISP. Username: Enter the username provided by your ISP. You can input up to 128 alphanumeric characters (case sensitive). This is in the format of “username@ispname” instead of simply “username”. Password: Enter the password provided by your ISP.

  • Page 35: Wlan (Only Available For 7300N)

    4.4 WLAN (Only available for 7300N) WLAN Service: Default setting is set to Enable. ESSID: The ESSID is the unique name of a wireless access point (AP) to be distinguished from another. For security propose, change to a unique ID name to the AP which is already built-in to the router’s wireless interface.
  • Page 36 Security Parameters WPA / WPA2 WLAN Service: Default setting is set to Enable. If you want to use wireless, you can select Enable. ESSID: The ESSID is the unique name of a wireless access point (AP) used to distinguish one from another. For security propose, change to a unique ID name which is already built into the router wireless interface.
  • Page 37 RADIUS Server IP Address: The IP address of RADIUS authentication server. RADIUS Server Port: The port number of RADIUS authentication server here. Default value is 1812. RADIUS Shared Secret: The password of RADIUS authentication server. WPA / WPA2 Pre-Shared Key WPA and WPA2 pre-shared keys are an authentication mechanism in which users provide some form of credentials to verify that they should be allowed access to a network.
  • Page 38 characters. Make sure your wireless clients have exactly the ESSID as the device in order to connect to your network. Hide ESSID: This function enables the router to become invisible on the network. Thus, any clients using the wireless setting to search for available or specific router on the network will not be able to discover the router whose Hide ESSID function is set to enabled.
  • Page 39 WLAN Service: Default setting is set to Enable. If you do not have any wireless, select Disable. ESSID: The ESSID is the unique name of a wireless access point (AP) used to distinguish one from another. For security propose, change to a unique ID name which is already built into the router wireless interface.
  • Page 40 Note: Wireless performance may degrade if the selected channel ID is already being occupied Security Mode: You can disable or enable with WPA or WEP to protect wireless network. The default mode of wireless security is Disable. RADIUS / 802.1x: You can disable or enable the RADIUS service. WEP Authentication: To prevent an unauthorized wireless station from accessing the data transmitted over the network, the router offers a secure data encryption, known as WEP.

  • Page 41: Chapter 5

    Chapter 5 Advanced Configuration Once you have logged on to your BiPAC 7300(N) Router via your web browser, you can begin to set it up according to your requirements. On the configuration homepage, the left navigation pane links you directly to the setup pages, which include: Basic (Switch to Basic Configuration Mode) Status (ADSL Status, ARP Table, DHCP Table, System Log, Firewall Log, UPnP Portmap) Quick Start...

  • Page 42: Status

    5.1 Status Device Information Host Name: Provide a name for the router for identification purposes. Host Name lets you change the router name.
  • Page 43 System Up-Time: Records system up-time. Current time: Set the current time. See the Time Zone section for more information. Hardware Version: Device version. Software Version: Firmware version. MAC Address: The LAN MAC address. Port: Name of the WAN connection. Protocol VPI/VCI: Virtual Path Identifier and Virtual Channel Identifier Operation: Current available operation.

  • Page 44: Adsl Status

    5.1.1 ADSL Status DSP Firmware Version: DSP code version DMT Status: Current DMT Status Operational Mode: To show the state when user select “AUTO” on connect mode. Upstream: Upstream rate. Downstream: Downstream rate. SNR Margin (Upstream): This is noise margin in upstream. SNR Margin (Downstream): This is noise margin in downstream.
  • Page 45 Multimode”,”ADSL2”, ”ADSL2+”,”G.Lite”, “T1.413” and “G.DMT” that user can select for this connection.

  • Page 46: Arp Table

    5.1.2 ARP Table This section displays the router’s ARP (Address Resolution Protocol) Table, which shows the mapping of Internet (IP) addresses to Ethernet (MAC) addresses. This is useful as a quick way of determining the MAC address of the network interface of your PCs to use with the router’s Firewall –...

  • Page 47: System Log

    5.1.4 System Log Display system logs accumulated up to the present time. You can trace historical information with this function. 5.1.5 Firewall Log Firewall Log displays log information of any unexpected action with your firewall settings. This page displays the router’s Firewall Log entries. The log shows log entries when you have enabled Intrusion Detection or Block WAN PING in the Configuration –...

  • Page 48: Upnp Portmap

    5.1.6 UPnP Portmap The section lists all port-mapping established using UPnP (Universal Plug and Play). Please see the Advanced section of this manual for more details on UPnP and the router’s UPnP configuration options.

  • Page 49: Quick Start

    5.2 Quick Start ADSL Connect mode: ADSL Protocol: The current ATM protocol in the device VPI / VCI: The current value of VPI / VCI in the device IP address: To show current value of IP address in the device. EWAN Click on Continue to choose the Protocol to connect with EWAN or click Jump to Wireless Setting to use Protocol: Obtain an IP Address Automatically to connect and setup wireless...
  • Page 50 Obtain an IP Address Automatically When connecting to the ISP, BiPAC 7300(N) also functions as a DHCP client. BiPAC 7300(N) can automatically obtain an IP address, subnet mask, gateway address, and DNS server addresses if the ISP assigns this information via DHCP. Protocol: The current ATM protocol in the device Click on the Continue button and wait for your connection to be connected.
  • Page 51 Fixed IP Address Select this option to set static IP information. You will need to enter in the Connection type, IP address, Netmask, and gateway address, provided to you by your ISP. Each IP address entered in the fields must be in the appropriate IP form, which is four IP octets separated by a dot (x.x.x.x).
  • Page 52 PPPoE PPPoE (PPP over Ethernet) provides access control in a manner similar to dial-up services using PPP. Protocol: The current ATM protocol in the device Username: Enter the username provided by your ISP. You can input up to 128 alphanumeric characters (case sensitive). This is in the format of “username@ispname” instead of simply “username”.

  • Page 53: Set Wireless Configuration

    Set Wireless configuration WLAN Service: Default setting is set to Enable. ESSID: The ESSID is the unique name of a wireless access point (AP) to be distinguished from another. For security propose, change to a unique ID name to the AP which is already built-in to the router’s wireless interface.

  • Page 54: Configuration

    5.3 Configuration Click this item to access the following sub-items that configure the ADSL router: LAN, WAN, System, Firewall, QoS, Virtual Server, Wake on LAN, Time Schedule and Advanced. These functions are described in the following sections. 5.3.1 LAN (Local Area Network) A Local Area Network (LAN) is a shared communication system to which many computers are attached and is limited to the immediate area, usually the same building or floor of a building.
  • Page 55 The router supports more than one Ethernet IP addresses in the LAN, and with distinct LAN subnets through which you can access the Internet at the same time. Users usually only have one subnet in their LAN. The default IP address for the router is 192.168.1.254. IP Address: The default IP on this router.
  • Page 56 5.3.1.3 Wireless (Only available for 7300N) Parameters WLAN Service: Default setting is set to Enable. Mode: The default setting is 802.11g+n (Mixed mode). If you do not know or have both 11g and 11n devices in your network, then keep the default in mixed mode. From the drop-down manual, you can select 802.11g if you have only 11g card.
  • Page 57 no one will be able to locate the Access Point (AP) of your router. Disable: When Disable is selected, you can allow anybody with a wireless client to be able to locate the Access Point (AP) of your router. Regulation Domain: There are seven Regulation Domains for you to choose from, including North America (N.America), Europe, France, etc.
  • Page 58 2. Peer WDS MAC Address: It is the second associated AP’s MAC Address. 3. Peer WDS MAC Address: It is the third associated AP’s MAC Address. 4. Peer WDS MAC Address: It is the fourth associated AP’s MAC Address. Note: For MAC Address, Semicolon ( : ) or Dash (-) must be included. 5.3.1.4 Wireless Security (Only available for 7300N) You can disable or enable with WPA or WEP for protecting wireless network.
  • Page 59 Security Mode: You can choose the type of security mode you want to apply from the drop down menu. RADIUS/802.1x: Whether to enable RADIUS function or not (For WPA/WPA2/WEP encryption). WPA Algorithms: There are 3 types of the WPA-PSK, WPA2-PSK & WPA/WPA2-PSK. The WPAPSK adapts the TKIP (Temporal Key Integrity Protocol) encrypted algorithms, which incorporates Message Integrity Code (MIC) to provide protection against hackers.
  • Page 60 Default Used WEP Key: Select the encryption key ID; please refer to Key (1~4) below. Passphrase: This is used to generate WEP keys automatically based upon the input string and a pre-defined algorithm in WEP64 or WEP128. Key (1-4): Enter the key to encrypt wireless data. To allow encrypted data transmission, the WEP Encryption Key values on all wireless stations must be the same as the router.
  • Page 61 PIN Method & Method. Wi-Fi Network Setup (only for BiPAC 7300N) PIN Method: Configure AP as Registrar 1. Jot down the client’s Pin (eg. 16837546). 2. Enter the Enrollee’s PIN number and then press Start. 3. Launch the wireless client’s WPS utility (eg. Ralink Utility). Set the Config Mode as Enrollee, press the WPS button on the top bar, select the AP (eg.
  • Page 62 4. The client’s SSID and security setting will now be configured to match the SSID and security setting of the registrar.
  • Page 63 PIN Method: Configure AP as Enrollee 1. In the WPS configuration page, change the Role to Enrollee. Then press Start. 2. Jot down the WPS PIN (eg. 25879810). 3. Launch the wireless client’s WPS utility (eg. Ralink Utility). Set the Config Mode as Registrar.
  • Page 64 The router’s (AP’s) SSID and security setting will now be configured to match the SSID and security setting of the registrar.
  • Page 65 5. Now to make sure that the setup is correctly done, cross check to see if the SSID and the security setting of the registrar setting match with the parameters found on both Wireless Configuration and Wireless Security Configuration page.
  • Page 67 PBC Method: 1. Press the PBC button of the AP. 2. Launch the wireless client’s WPS Utility (eg. Ralink Utility). Set the Config Mode as Enrollee. Then press the WPS button and choose the correct AP (eg. wlan-ap) from the WPS AP List section before pressing the PBC button to run the scan.
  • Page 68 3. When the PBC button is pushed, a wireless communication will be established between your router and the PC. The client’s SSID and security setting will now be configured to match the SSID and security setting of the router. Wi-Fi Network Setup with Windows Vista WCN: 1.
  • Page 69 3. In your Vista operating system, access the Control Panel page, then select Network and Internet > View Network Computers and Devices. Double click on the BiPAC 7300N icon and enter the AP PIN in the column provided then press Next.
  • Page 70 5. Enter the passphrase then click Next.
  • Page 71 6. When you have come to this step, you will have completed the Wi-Fi network setup using the built-in WCN feature in Windows Vista.
  • Page 72 5.3.1.6 DHCP Server You can disable or enable the DHCP (Dynamic Host Configuration Protocol) server or enable the router’s DHCP relay functions. The DHCP protocol allows your router to dynamically assign IP addresses to PCs on your network if they are configured to obtain IP addresses automatically.
  • Page 73 DHCP Server Mode: DHCP Server To configure the router’s DHCP Server, check DHCP Server. You can then configure parameters of the DHCP Server including the IP pool (starting IP address and ending IP address to be allocated to PCs on your network), lease time for each assigned IP address (the period of time the IP address assigned will be valid), DNS IP address and the gateway IP address.

  • Page 74: Wan (Wide Area Network)

    assigns an IP address back to the DHCP client in the LAN. Use this function only if advised to do so by your network administrator or ISP. Click Apply to enable this function. 5.3.2 WAN (Wide Area Network) A WAN (Wide Area Network) is an outside connection to another network or the Internet. There are two items within the WAN section: WAN Profile and ADSL Mode.
  • Page 75 5.3.2.1 WAN Profile Main Port--ADSL PPPoE Connection (ADSL) PPPoE (PPP over Ethernet) provides access control in a manner similar to dial-up services using PPP. Description: A user-definable name for this connection. VPI/VCI: Enter the VPI and VCI information provided by your ISP. Encap.
  • Page 76 IP Address: Your WAN IP address. Leave this at 0.0.0.0 to automatically obtain an IP address from your ISP. Auth. Protocol: Default is Auto. Your ISP advises on using Chap or Pap. Obtain DNS Automatically: Select this check box to use DNS. Primary DNS/ Secondary DNS: Enter the IP addresses of the DNS servers.
  • Page 77 Description: User-definable name for the connection. VPI/VCI: Enter the VPI and VCI information provided by your ISP. Encapsulation method: Select the encapsulation format, the default is LLC. Select the one provided by your ISP Username: Enter the username provided by your ISP. You can input up to 128 alphanumeric characters (case sensitive).
  • Page 78 MPoA Connection (ADSL) Description: Your description of this connection. VPI and VCI: Enter the VPI and VCI information provided by your ISP. Encap. method: Select the encapsulation format, the default is LLC. Select the one provided by your ISP. Encap. mode: Choose whether you want the device to function as bridge mode or routing mode.
  • Page 79 Pure Bridge Connections (ADSL) Description: A user-definable name for this connection. VPI/VCI: Enter the VPI and VCI information provided by your ISP. Encap. method: Select the encapsulation format, this is provided by your ISP.
  • Page 80 Main Port—EWAN Besides using ADSL to get connected to the Internet, BiPAC 7300(N) offers its Ethernet port 1 as a WAN port to be used to connect to Cable Modems, VDSL and fibre optic lines. This alternative, yet faster method to connect to the internet will provide users with more flexibility to get online Obtain an IP Address Automatically (EWAN) When connecting to the ISP, BiPAC 7300(N) also functions as a DHCP client.
  • Page 81 Fixed IP Address (EWAN) Select this option to set static IP information. You will need to enter in the Connection type, IP address, netmask, and gateway address, provided to you by your ISP. Each IP address entered in the fields must be in the appropriate IP form, which is four IP octets separated by a dot (x.x.x.x).
  • Page 82 PPPoE (EWAN) PPPoE (PPP over Ethernet) provides access control in a manner similar to dial-up services using PPP. Line Speed: Set the downstream and upstream of your connection in kilobytes per second. The connection speed is used by QoS settings. Username: Enter the username provided by your ISP.
  • Page 83 5.3.2.3 ADSL Mode ADSL Mode: There are four modes “Open Annex Type and Follow DSLAM’s Setting”, ”Annex A”, ”Annex L”, ”Annex M” and “Annex J” that user can select for this connection. Modulator: There are seven modes “AUTO”,”ADSL multimode”,”ADSL2”,”ADSL2+”, “G.Lite:”, “T1.413” and “G.DMT” that user can select for this connection.

  • Page 84: System

    5.3.3 System There are five items within the System section: Time Zone, Firmware Upgrade, Backup/Restore, Restart, User Management and Mail Alert.

  • Page 85: Time Zone

    5.3.3.1 Time Zone The router does not have a real time clock on board; instead, it uses the Simple Network Time Protocol (SNTP) to get the current time from an SNTP server outside your network. Choose your local time zone, click Enable and click the Apply button. After a successful connection to the Internet, the router retrieves the correct local time from the SNTP server you have specified.
  • Page 86 5.3.3.2 Firmware Upgrade Your router’s “firmware” is the software that allows it to operate and provides all its functionality. Think of your router as a dedicated computer, and the firmware as the software it runs. Over time this software may be improved and modified. Your router allows you to upgrade the software it runs to take advantage of these changes.
  • Page 87 5.3.3.3 Backup / Restore These functions allow you to save and backup your router’s current settings to a file on your PC, or to restore a previously saved backup. This is useful if you wish to experiment with different settings, knowing that you have a backup handy in the case of any mistakes. It is advisable to backup your router’s settings before making any significant changes to your router’s configuration.
  • Page 88 5.3.3.4 Restart Router Click Restart with option Current Settings to reboot your router and save the current configuration to device. If you wish to restart the router using the factory default settings (for example, after a firmware upgrade or if you have saved an incorrect configuration), select Factory Default Settings to reset to factory default settings.

  • Page 89: Firewall

    You are strongly advised to change the password on the default “admin” account when you receive your router, and any time you reset your configuration to Factory Defaults. 5.3.3.6 Mail Alert Send a log via email, if WAN IP is changed or if intruders accessing your computer without permission.
  • Page 90 Firewall: Prevents access from outside your network. NAT natural firewall: This masks LAN users’ IP addresses, which are invisible to outside users on the Internet, making it much more difficult for a hacker to target a machine on your network. This natural firewall is on when the NAT function is enabled. When using Virtual Servers (port mapping) your PCs are exposed to the ports specified opened in your firewall packet filter settings.
  • Page 91 A detailed explanation of each of the following five items appears in the Firewall section below: Packet Filter, MAC Address Filter, Intrusion detection, Block WAN PING and URL Filter. 5.3.4.1 Packet Filter Packet filtering enables you to configure your router to block specified internal/external users (IP address) from Internet access, or you can disable specific service requests (Port number) to /from Internet.
  • Page 92 Rule Name: Users-define description to identify this entry. The maximum name length is 32 characters, and then can choose application that they want from listbox. Internal IP Address / External IP Address: This is the Address-Filter used to allow or block traffic to/from particular IP address(es).

  • Page 93: Mac Filter

    Reorder: Be aware that packet filtering parameters appear in priority order i.e. the first one takes precedence over all other rules. There is a sort function next to the Rule Name column, you can move the rule to higher or lower priority by clicking the Order arrow, and press “Reorder”...
  • Page 94 The format of MAC address could be: xx:xx:xx:xx:xx:xx or xx-xx-xx-xx-xx-xx. Filter Action Action: Select an action for MAC Filter. This feature is disabled by default. Check Allow or Block to activate the filter. Parameters MAC Address: Enter the ethernet MAC addresses you wish to have the filter rule applies.

  • Page 95: Intrusion Detection

    5.3.4.3 Intrusion Detection Check Enable if you wish to detect intruders accessing your computer without permission. The router automatically detects and blocks a DoS (Denial of Service) attack if a user enables this function. This kind of attack is not to access confidential data on the network; instead, it aims to disrupt specific equipment or the entire network.
  • Page 96 For SYN Flood, ICMP Echo Storm and ICMP flood, IDS will just warn the user in the Event Log but it will not be able to protect against such attacks. Hacker attack types recognized by the IDS Type of Block Intrusion Name Detect Parameter Blacklist Drop Packet Show Log...

  • Page 97: Block Wan Ping

    Src IP: Source IP Src Port: Source Port Dst Port: Destination Port Dst IP: Destination IP 5.3.4.4 Block WAN PING Check Enable if you wish to exclude outside PING requests from reaching this router. 5.3.4.5 URL Filter URL (Uniform Resource Locator – e.g. an address in the form of http://www.example.com filter rules allow you to prevent users on your network from accessing particular websites from their URL.
  • Page 98 “abcde” occurs in the URL. Domains Filtering: Checks the domain name in URLs accessed against your list of domains to block or allow. If it matches, the URL request is sent (Trusted) or dropped (Forbidden). The checking procedure is: 1. Check the domain in the URL to determine if it is in the trusted list. If yes, the connection attempt is sent to the remote web server.
  • Page 99 Block Cookies: Blocks Cookies Block Proxy: Blocks Proxy Except IP Address: Time Schedule: It is self-defined time period. You may specify a time schedule for your prioritization policy. For setup and detail, refer to Time Schedule section. Log: Click “Log” if you wish to generate logs when the filer rule is applied to the URL Filter.

  • Page 100: Qos (Quality Of Service)

    5.3.5 QoS (Quality of Service) Quality of Service Introduction If you’ve ever found your ‘net’ speed has slowed to a crawl because another family member is using a P2P file sharing program, you’ll understand why the Quality of Service features in the routers is such a breakthrough for home users and office users.
  • Page 101 There are two settings to be provided in the Router: LAN to WAN: You want to control the traffic flow from the local network to the outside world. e.g., you have a FTP server inside the local network and you want to have a limited traffic rate controlled by the QoS policy.
  • Page 102 DSCP Mapping Table ADSL2+ Router Standard DSCP Disabled None Best Effort Best Effort (000000) Premium Express Forwarding (101110) Gold service (L) Class 1, Gold (001010) Gold service (M) Class 1, Silver (001100) Gold service (H) Class 1, Bronze (001110) Silver service (L) Class 2, Gold (010010) Silver service (M) Class 2, Silver (010100)
  • Page 103 Priority: Specify the priority for the bandwidth that is not used. For examples, you may specify two different QoS policies for different applications. Both applications need a minimal bandwidth and need more bandwidth, beside the assigned one, if there is any available/non-used one available.

  • Page 104: Connection Diagram

    QoS example for your Network Connection Diagram VoIP HTTP web Normal PCs browsing users Restricted PC ADSL Subscription Rate Upstream: 256 kbps Downstream: 2048 Mbps Example QoS Plan Application IP or Ports Control Flow Data Rate Time Schedule VoIP User 192.168.1.1 Outgoing Minimal 20% with high priority...
  • Page 105 Example QoS Setup VoIP application Voice is latency-sensitive application. Most VoIP devices are used SIP protocol and the port number will be assigned by SIP module automatically. Better to use fixed IP address for catching VoIP packets as high priority.

  • Page 106: Virtual Server

    5.3.6 Virtual Server In TCP and UDP networks a port is a 16-bit number used to identify which application program (usually a server) incoming connections should be delivered to. Some ports have numbers that are pre-assigned to them by the IANA (the Internet Assigned Numbers Authority), and these are referred to as “well-known ports”.
  • Page 107 designated as “well-known ports”. The registered ports are numbered from 1024 through 49151. The remaining ports, referred to as dynamic ports, or private ports, are numbered from 49152 through 65535. Examples of well-known and registered port numbers are shown below, for further information, please see IANA’s website at: http://www.iana.org/assignments/port-numbers Well-known and Registered Ports...

  • Page 108: Port Mapping

    5.3.6.1 Port Mapping Application: Select the service you wish to configure Protocol: Automatic when you choose Application from listbox or select a protocol type which you want. External Port & Internal Port: Enter the public port number & range you wish to configure.
  • Page 109 In addition to specifying the port number used, you also need to specify the protocol used. The protocol is determined by the particular application. Most applications use TCP or UDP, however you can specify other protocols using the drop-down Protocol menu. Setting the protocol to “all”...
  • Page 110 5.3.6.3 ALG Controls enable or disable various protocols over application layer. For example, SIP ALG: Enable: When SIP phone need ALG to pass through the NAT. Disable: When SIP phone included NAT-Traversal algorithm. Turn off the SIP ALG. Using port mapping does have security implications, since outside users are able to connect to PCs on your network.

  • Page 111: Wake On Lan

    5.3.7 Wake on LAN This feature provides greater flexibility for users to turn on / boot the computer of the network from a remotely site. MAC Address: Enter the MAC address of the target computer or you can select the MAC address directly from the Select drop down menu on the right.
  • Page 112 Name: A user-define description to identify this time portfolio. Day in a week: The default is set from Sunday through Saturday. You may specify the days for the schedule to be applied. Start Time: The default is set at 8:00 AM. You may specify the start time of the schedule. End Time: The default is set at 18:00 (6:00PM).

  • Page 113: Advanced

    5.3.9 Advanced Configuration options within the Advanced section are for users who wish to take advantage of the more advanced features of the router. Users who do not understand the features should not attempt to reconfigure their router, unless advised to do so by support staff.

  • Page 114: Static Route

    5.3.9.1 Static Route Destination: The destination subnet IP address. Netmask: Subnet mask of the destination IP addresses based on above destination. Gateway: The gateway IP address to which packets are forwarded. Interface: Select the interface through which packets are forwarded. Cost: Represents the cost of transmission for routing purposes.
  • Page 115 Delete: To remove a static ARP entry, check the Delete box of the selected entry then click the "Edit/Delete" button. 5.3.9.3 Dynamic DNS The Dynamic DNS function lets you alias a dynamic IP address to a static hostname, so if your ISP does not assign you a static IP address you can still use a domain name.
  • Page 116 Period: Set the time period between updates, for the Router to exchange information with the DDNS server. In addition to updating periodically as per your settings, the router will perform an update when your dynamic IP address changes. If the period is 0, the router will check the DNS server every 5 min.
  • Page 117 HTTP Port: The port number of the router’s embedded web server (for web-based configuration uses. The default value is the standard HTTP port, 80. You may specify an alternative if, for example, you are running a web server on a PC within your LAN. For Example: User A changes HTTP port number to 100, specifies their own IP address of 192.168.1.55, and sets the logout time to be 100 minutes.
  • Page 119 Step 3: In the Communications window, select the Universal Plug and Play check box in the Components selection box. Step 4: Click OK to go back to the Add/Remove Programs Properties window. Click Next. Step 5: Restart the computer when prompted. Follow the steps below to install the UPnP in Windows XP.
  • Page 120 Step 4: Select Networking Service in the Components selection box and click Details. Step 5: In the Networking Services window, select the Universal Plug and Play check box. Step 6: Click OK to go back to the Windows Optional Networking Component Wizard window and click Next.
  • Page 121 Auto-discover Your UPnP-enabled Network Device Step 1: Click start and Control Panel. Double-click Network Connections. An icon displays under Internet Gateway. Step 2: Right-click the icon and select Properties. Step 3: In the Internet Connection Properties window, click Settings to see the port mappings that were automatically created.
  • Page 122 Step 5: Select Show icon in notification area when connected option and click OK. An icon displays in the system tray Step 6: Double-click on the icon to display your current Internet connection status. Web Configurator Easy Access With UPnP, you can access web-based configuration for the BiPAC 7300(N) without first...
  • Page 123 finding out the IP address of the router. This helps if you do not know the router’s IP address. Follow the steps below to access web configuration. Step 1: Click Start and then Control Panel. Step 2: Double-click Network Connections. Step 3: Select My Network Places under Other Places.
  • Page 124 5.3.9.6 IGMP IGMP, known as Internet Group Management Protocol, is used to management hosts from multicast group. IGMP Proxy: Accepting multicast packet. Default is set to Disable. IGMP Snooping: Allowing switched Ethernet / Wireless to check and make correct forwarding decisions. Default is set to Disable. 5.3.9.7 SNMP Access Control Software on a PC within the LAN is required in order to utilize this function –...
  • Page 125 configuration file. Once the string name is matched, users from this IP address will be able to view and modify the data. Trap Community: Specify a name to be identified as the Trap Community, and an IP address. This community string will be checked against the string entered in the configuration file.
  • Page 126 From RFC1650 (EtherLike-MIB): dot3Stats From RFC 1493 (Bridge MIB): dot1dBase group dot1dTp group dot1dStp group (if configured as spanning tree) From RFC 1471 (PPP/LCP MIB): pppLink group pppLqr group From RFC 1472 (PPP/Security MIB): PPP Security Group) From RFC 1473 (PPP/IP MIB): PPP IP Group From RFC 1474 (PPP/Bridge MIB): PPP Bridge Group...
  • Page 127 5.3.9.8 Remote Access Remote Access Control: Enable: Select Enable to allow management access from remote side (mostly from internet). Duration: Set how many minutes to allow management access from remote side. Zero means always on. Allowed Access IP Address Range: Valid: Select Valid to allow remote management from these IP ranges.

  • Page 128: Save Configuration To Flash

    5.4 Save Configuration to Flash After changing the router’s configuration settings, you must save all of the configuration parameters to FLASH to avoid losing them after turning off or resetting your router. Click “Save Config“ and click “Apply” to write your new configuration to FLASH. 5.5 Restart Click Restart with option Current Settings to reboot your router (and restore your last saved configuration).

  • Page 129: Logout

    5.6 Logout To exit the router’s web interface, choose Logout. Please ensure that you have saved the configuration settings before you logout. Be aware that the router is restricted to only one PC accessing the configuration web pages at a time. Once a PC has logged into the web interface, other PCs cannot get access until the current PC has logged out of the web interface.

  • Page 130: Chapter 6

    Chapter 6 Troubleshooting If your ADSL Router is not functioning properly, you can refer first to this chapter for simple troubleshooting before contacting your service provider support. This can save you time and effort but if symptoms persist, consult your service provider. Problems starting up the router Problem Corrective Action...
  • Page 131 Frequent loss Ensure that all other devices connected to the same ADSL linesync telephone line as your router (e.g. telephones, fax machines, (disconnections). analogue modems) have a line filter connected between them and the wall socket (unless you are using a Central Splitter or Central Filter installed by a qualified and licensed electrician), and ensure that all line filters are correctly installed and the right way around.
