Billion VoIP/(802.11g) ADSL2+ Router BiPAC 7300VGP Quick Start Manual

Billion voip/(802.11g) adsl2+ router quick start guide
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
BiPAC 7300VP/ 7300VGP
VoIP/(802.11g) ADSL2+ Router
Quick Start Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VoIP/(802.11g) ADSL2+ Router BiPAC 7300VGP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Billion VoIP/(802.11g) ADSL2+ Router BiPAC 7300VGP

Summary of Contents for Billion VoIP/(802.11g) ADSL2+ Router BiPAC 7300VGP

  • Page 1 BiPAC 7300VP/ 7300VGP VoIP/(802.11g) ADSL2+ Router Quick Start Guide...

  • Page 3: Package Contents

    For more detailed instructions on configuring and using the VoIP/802.11g ADSL2+ Router, please refer to the on-line manual. Package Contents VoIP/(802.11g) ADSL2+ Router CD-ROM containing the on-line manual RJ-11 ADSL/telephone Cable Ethernet (CAT-5 LAN) Cable AC-DC power adapter (12VDC, 1.2A) This Quick Start Guide Do not use the BiPAC 7300VGP Series in high humidity or high temperatures.

  • Page 4: The Front Leds

    Quick Start Guide The Front LEDs PWR： SYS： LAN Port 1-4： WLAN： (7300VGP only) Phone： LINE： VoIP： PPP： ADSL： Description Lights when the power is ON. Lights when the system is ready. Steady glow when connected to an Ethernet device. Glows green for 100Mbps;...

  • Page 5: The Rear Ports

    The Rear Ports Port Power Switch RESET Phone LINE ADSL Antenna (7300VGP only) Billion BiPAC 7300VGP Series ADSL2+ Router Description Power ON/OFF switch. Connect the supplied power adapter to this jack. After the router is powered on, press this recessed button using the end of paper clip or other small pointed object to reset the router or to restore it to factory default settings.
  • Page 6 Quick Start Guide Connecting BiPAC 7300VGP series 1. Connect the Router to a LAN (Local Area Network) and the ADSL/telephone (LINE) network. 2. Power on the device. 3. Make sure the PWR and SYS LEDs are lit steadily and that the relevant LAN LED is lit. 4.

  • Page 7: Configuring Pc In Windows Xp

    Configuring PC in Windows XP 1. Go to Start / Control Panel (in Classic View). In the Control Panel, double-click on Network Connections 2. Double-click Local Area Connection. 3. In the Local Area Connection Status window, click Properties. 4. Select Internet Protocol (TCP/IP) and click Properties.

  • Page 8: Configuring Pc In Windows 2000

    Quick Start Guide Configuring PC in Windows 2000 Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and Dial-up Connections. 2. Double-click Local Area Connection. 3. In the Local Area Connection Status window click Properties. 4.

  • Page 9: Configuring Pc In Windows 98/Me

    Configuring PC in Windows 98/Me 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and choose the Configuration tab. 2. Select TCP/IP -> NE2000 Compatible, or the name of your Network Interface Card (NIC) in your PC. 3.
  • Page 10 Quick Start Guide Configuring PC in Windows NT4.0 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and choose the Protocols tab. 2. Select TCP/IP Protocol and click Properties. 3. Select the Obtain an IP address from a DHCP server radio button and click OK.
  • Page 11 Configuring Your (802.11g)/VoIP ADSL2+ Router 1. To configure this device, you must have IE 5.0 / Netscape 4.5 or above installed 2. You may configure the router for Internet access in two ways: Easy Sign On: User just installs all of cables and uses the browser to surf Internet. At this time, the EZSO WEB GUI will be popped up and request you to input some basic information you get from ISP.
  • Page 12 Quick Start Guide Web Configuator: Open the web browser and type http://192.168.1.254 address box. This number is the default IP address for this router. Press Enter. 2. A username and password window will appear. The default username and password are admin and admin. Press OK to proceed.

  • Page 13: Verifying Your Local Network Connection With The Device

    Verifying Your Local Network Connection with the Device To see if this ADSL Router is visible on the local network, go to Start / Run. In the Run dialog box, type “ping 192.168.1.254” then press OK. A command prompt window will pop out.

This manual is also suitable for:

Bipac 7300vgpBipac 7300vp
