Billion BiPAC 7300VGP User Manual

Voip/(802.11g) adsl2+ router
Hide thumbs Also See for BiPAC 7300VGP:
Table of Contents

Advertisement

Quick Links

Download this manual
BiPAC 7300VP/7300VGP
VoIP/(802.11g) ADSL2+ Router
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BiPAC 7300VGP and is the answer not in the manual?

Questions and answers

Related Manuals for Billion BiPAC 7300VGP

Summary of Contents for Billion BiPAC 7300VGP

  • Page 1 BiPAC 7300VP/7300VGP VoIP/(802.11g) ADSL2+ Router User’s Manual...

  • Page 2: Table Of Contents

    Chapter 1 ... 2 1.1 Introducing the BiPAC 7300VGP series ... 2 1.2 Features... 4 1.3 Applications of the BiPAC 7300VGP series... 8 Chapter 2 ... 9 2.1 Important Notes ... 10 2.2 Package Contents... 10 2.3 The Front LEDs... 11 2.4 The Rear Ports ...

  • Page 3: Chapter 1

    Translation (NAT), it also provides rich firewall features to secure your network. All incoming data packets are monitored and filtered. You can also configure your new router to block internal users from accessing the Internet. The BiPAC 7300VGP series provides two levels of security support. First, it masks LAN IP...
  • Page 4 You can set an ISP (Internet Service Provider) provided IP address on the BiPAC 7300VGP series and then you can reroute specific services to individual computers on your local network. For...

  • Page 5: Features

    1.2 Features Express Internet Access – ADSL2/2+ capable The BiPAC 7300VGP series complies with ADSL worldwide standards. Supporting downstream rates of 8Mbps with ADSL, the router is capable of up to 12/24 Mbps with ADSL2/2+, and upstream rates of up to 1 Mbps. Users enjoy not only high-speed ADSL services but also broadband multimedia applications such as interactive gaming, video streaming and real-time audio which are easier and faster than ever.
  • Page 6 (RFC1577) to establish a connection with an ISP. The router also supports VC-based and LLC-based multiplexing. Quick Installation Wizard A web-based GUI and quick installation wizard help you easily install the BiPAC 7300VGP series. Enter your ISP’s information and begin browsing the Internet immediately. Universal Plug and Play (UPnP) and UPnP NAT Traversal...
  • Page 7 The BiPAC 7300VGP series provides an embedded PPPoE client function to establish a connection. You get greater access speed without changing the operation concept, while sharing the same ISP account and paying for one access account. No PPPoE client software is required for the local computer. Automatic Reconnect and Disconnect Timeout (Idle Timer) functions are also provided.
  • Page 8 A web-based GUI offers easy configuration and management. User-friendly and with on-line help, it also supports remote management capability for remote users to configure and manage this product. Firmware Upgradeable You can upgrade the router with the latest firmware through its web-based GUI.

  • Page 9: Applications Of The Bipac 7300Vgp Series

    1.3 Applications of the BiPAC 7300VGP series...

  • Page 10: Product Overview

    Keep the number of walls and ceilings between the BiPAC 7300VGP and other network devices to a minimum - each wall or ceiling can reduce your BiPAC 7300VGP wireless product’s range from 3-90 feet (1-30 meters.) Position your devices so that the number of walls or ceilings is minimized.Keep the number of walls and ceilings between the BiPAC 7300VGP and other network devices to a minimum - each wall or ceiling can reduce your BiPAC 7300VGP wireless product’s range...

  • Page 11: Important Notes

    (at least 3-6 feet or 1-2 meters) from electrical devices or appliances that generate extreme RF noise. 2.1 Important Notes Do not use the BiPAC 7300VGP series in high humidity or high temperatures. Do not use the same power source for the BiPAC 7300VGP series as other equipment.

  • Page 12: The Front Leds

    2.3 The Front LEDs PWR： SYS： LAN Port 1-4： WLAN： (7300VGP only) Phone： LINE： VoIP： PPP： ADSL： Description Lights when the power is ON. Lights when the system is ready. Steady glow when connected to an Ethernet device. Glows green for 100Mbps; Orange for 10Mbps.

  • Page 13: The Rear Ports

    Switch RESET Phone LINE ADSL Antenna (7300VGP only) Description Power ON/OFF switch. Connect the supplied power adapter to this jack. After the router is powered on, press this recessed button using the end of paper clip or other small pointed object to reset the router or to restore it to factory default settings.
  • Page 14 The detail instruction in Emergency/Failure Recovery Button 1. Recovery procedures for non-working routers (e.g. after a failed firmware upgrade flash): Hold the Emergency/Failure Recovery Button on the back of the modem in. Keep this button held in and turn on the modem. Once the lights on the modem have stopped flashing, release the Emergency/Failure Recovery Button.

  • Page 15: Cabling

    2.5 Cabling One of the most common causes of problems is bad cabling or ADSL line(s). Make sure that all connected devices are turned on. On the front of the product is a bank of LEDs. Verify that the LAN Link and ADSL line LEDs are lit. If they are not, verify that you are using the proper cables.

  • Page 16: Installation

    You can configure the BiPAC 7300VGP series router through the convenient and user-friendly interface of a web browser. Most popular operating systems such as Linux and Windows 98/NT/2000/XP/Me include a web browser as a standard application. 3.1 Before Configuration PCs must have a properly installed Ethernet interface and connect to the router directly or through an external repeater hub.

  • Page 17: Configuring A Pc In Windows Xp

    Configuring a PC in Windows XP 1. Go to Start / Control Panel (in Classic View). In the Control Panel, double-click on Network Connections 2. Double-click Local Area Connection. 3. In the Local Area Connection Status window, click Properties. 4. Select Internet Protocol (TCP/IP) and click Properties.

  • Page 18: Configuring A Pc In Windows 2000

    5. Select the Obtain an IP address automatically and the Obtain DNS server address automatically radio buttons. 6. Click OK to finish the configuration. Configuring a PC in Windows 2000 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and Dial-up Connections.

  • Page 19: Configuring Pc In Windows 98/Me

    4. Select Internet Protocol (TCP/IP) and click Properties. 5. Select the Obtain an IP address automatically and the Obtain DNS server address automatically radio buttons. 6. Click OK to finish the configuration. Configuring PC in Windows 98/Me 1.Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and choose the Configuration tab.
  • Page 20 3.Select the Obtain an IP address automatically radio button. 4.Then select the DNS Configuration tab. 5.Select the Disable DNS radio button and click OK to finish the configuration. Configuring PC in Windows NT4.0 1.Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and choose the Protocols tab.
  • Page 21 3.Select the Obtain an IP address from a DHCP server radio button and click OK.

  • Page 22: Factory Default Settings

    3.2 Factory Default Settings Before configuring the BiPAC 7300VGP series router, you need to know the following default settings. Web Interface: Username: admin Password: admin LAN Device IP Settings: IP Address: 192.168.1.254 Subnet Mask: 255.255.255.0 ISP setting in WAN site:...

  • Page 23: Information From Your Isp

    3.4 Information from your ISP Before configuring this device, you have to check with your ISP (Internet Service Provider) what kind of service is provided such as PPPoE, PPPoA, RFC1483, or IPoA. Gather the information as illustrated in the following table and keep it for reference. PPPoE VPI/VCI, VC-based/LLC-based multiplexing, Username, Password, Service Name, and Domain Name System (DNS) IP address (it can be...

  • Page 24: Configuring With Your (802.11G) Adsl2+ Router

    3.5 Configuring with your (802.11g) ADSL2+ Router 1. To configure this device, you must have IE 5.0 / Netscape 4.5 2. You may configure the router for Internet access in two ways: Easy Sign-On: User just installs all of cables and uses the browser to surf Internet. At this time, the EZSO WEB GUI will be popped up and request you to input some basic information you get from ISP.
  • Page 25 1. Please wait when the connection is trying. 3. If login failed, Please input the correct username and password again. 2.Enter the username and password provide by your ISP. 4. Login Successfully.
  • Page 26 DHCPWith this method, user does not need to access router to configure it and set lot of parameters. Besides, it eliminates the complicated way to configure the device and will definitely reduce the service call from users. 1. Please wait when the connection is trying. 2.

  • Page 27: Chapter 4

    Once you have logged on to your BiPAC 7300VGP series VoIP ADSL Router via your web browser, you can begin to set it up according to your requirements. On the configuration homepage, the left navigation pane links you directly to the setup pages, which include:...

  • Page 28: Status

    4.1 Status...
  • Page 29 Device Information Host Name: Provide a name for the router for identification purposes. Host Name lets you change the router name. System Up-Time: Records system up-time.
  • Page 30 Current time: Set the current time. See the Time Zone section for more information. Hardware Version: Chipset version Software Version: Firmware version Bootrom Version: Bootrom version MAC Address: The LAN MAC address Home URL: Connects to the Home Website. IP Address: LAN port IP address. Sub Net Mask: LAN port IP subnet mask.

  • Page 31: Arp Table

    4.1.1 ARP Table The router’s ARP (Address Resolution Protocol) Table shows the mapping of Internet (IP) addresses to Ethernet (MAC) addresses. This is a quick way to determine the MAC address of the network interface of your PCs to use with the router’s Firewall – MAC Address Filter function.

  • Page 32: Wireless Association

    4.1.2 Wireless Association IP Address: It is IP Address of wireless client that join this network. MAC: The MAC address of wireless client.

  • Page 33: Routing Table

    4.1.3 Routing Table Routing Table: #: Item number Destination: IP address of the destination network. Netmask: The destination netmask address. Gateway/Interface: IP address of the gateway or existing interface that this route uses. Cost: The cost of transmission for routing purposes. The number need not be precise, but it must be between 0 and 65535.

  • Page 34: Dhcp Table

    4.1.4 DHCP Table Leased: DHCP assigned IP addresses information. IP Address: IP addresses of devices on your LAN (Local Area Network). MAC Address: The MAC Address that you want to assign the fixed IP address Client Host Name: Expired IP addresses information Register Time: Register time information...

  • Page 35: System Log

    4.1.5 System Log Display system logs accumulated up to the present time. You can trace historical information with this function.

  • Page 36: Security Log

    4.1.6 Security Log This screen displays security log information. If a hacker attacks your server, he is isolated by the firewall function and the router records related information. This helps you know where the hacker comes from.

  • Page 37: Voip Log

    4.1.7 VoIP Log This screen displays VoIP log information. Any VoIP encountered by the router are logged to this window.

  • Page 38: Quick Start

    4.2 Quick Start For detailed instructions on configuring WAN settings, see the WAN section of this manual. The information you need for the Quick Start wizard to get you online are your login (often in the form of username@ispname), your password, and the encapsulation type. Your ISP can supply all the details you need.
  • Page 39 Connection Encapsulation: Select the encapsulation type your ISP uses or choose “Auto Scan”. Click Start to begin scanning for encapsulation types offered by your ISP. If the scan is successful, you are presented with a list of supported options. VCI: Enter the VCI assigned to you. This field may already be configured. VPI: Enter the VPI assigned to you.
  • Page 40 Optional Setting IP Address: Type your ISP assigned IP address in the IP Address text box. Subnet Mask: Enter a subnet mask in dotted decimal notation. Default Gateway: You must specify a gateway IP address (supplied by your ISP) Obtain DNS automatically: Select this check box to use DNS. Primary DNS: Enter the IP addresses of the DNS servers.

  • Page 41: Configuration

    4.3 Configuration Click this item to access the following sub-items that configure the ADSL router: LAN, WAN, System, Firewall, QoS, Virtual Server, Advanced and VoIP. These functions are described in the following sections.

  • Page 42: Lan (Local Area Network)

    4.3.1 LAN (Local Area Network) 4.3.1 LAN (Local Area Network) A Local Area Network (LAN) is a shared communication system to which many computers A Local Area Network (LAN) is a shared communication system to which many computers are attached and is limited to the immediate area, usually the same building or floor of a are attached and is limited to the immediate area, usually the same building or floor of a building.
  • Page 43 4.3.1.2 Wireless (7300VGP only) Mode: 802.11b + g (Mixed mode), 802.11b and 802.11g. The factory default is 802.11b + g. ESSID: Enter the unique ID given to the Access Point (AP), which is already built-in to the router’s wireless interface. To connect to this device, your wireless clients must have the same ESSID as the device.

  • Page 44: Wpa Pre-Shared Key

    (Note: For MAC Address, Semicolon ( : ) must be included) 4.3.1.3 Wireless Security (7300VGP only) You can disable or enable with WPA or WEP for protecting wireless network. The default mode of wireless security is disabled.

  • Page 45: Wpa2 Pre-Shared Key

    Group Key Renewal: The period of renewal time for changing the security key automatically between wireless client and Access Point (AP). Hide ESSID: User can select Enable or Disable to hide ESSID. WPA2 Pre-Shared Key WPA2 Algorithms: TKIP (Temporal Key Integrity Protocol) utilizes a stronger encryption method and incorporates Message Integrity Code (MIC) to provide protection against hackers.

  • Page 46: Dhcp Server

    WEP Encryption: To prevent unauthorized wireless stations from accessing data transmitted over the network, the router offers highly secure data encryption, known as WEP. If you require high security for transmissions, there are two alternatives to select from: WEP 64 and WEP 128. WEP 128 will offer increased security over WEP 64. Passphrase: This is used to generate WEP keys automatically based upon the input string and a pre-defined algorithm in WEP64 or WEP128.
  • Page 47 To disable the router’s DHCP Server, check Disabled and click Next then click Apply. When the DHCP Server is disabled you need to manually assign a fixed IP address to each PC on your network, and set the default gateway for each PC to the IP address of the router (the default is 192.168.1.254).
  • Page 48 If you check DHCP Relay Agent and click Next then you must enter the IP address of the DHCP server which assigns an IP address back to the DHCP client in the LAN. Use this function only if advised to do so by your network administrator or ISP. Click Apply to enable this function.

  • Page 49: Wan (Wide Area Network)

    4.3.2 WAN (Wide Area Network) A WAN (Wide Area Network) is an outside connection to another network or the Internet. There are three items within the WAN section: ISP, DNS and ADSL. 4.3.2.1 ISP The factory default is PPPoE. If your ISP uses this access protocol, click Edit to input other parameters as below.
  • Page 50 Description: Your description of this connection. VPI and VCI: Enter the information provided by your ISP. NAT: The NAT (Network Address Translation) feature allows multiple users to access the Internet through a single IP account, sharing the single IP address. If users on your LAN have public IP addresses and can access the Internet directly, the NAT function can be disabled.
  • Page 51 Description: User-definable name for the connection. VPI/VCI: Enter the information provided by your ISP. NAT: The NAT (Network Address Translation) feature allows multiple users to access the Internet through a single IP account, sharing a single IP address. If users on your LAN have public IP addresses and can access the Internet directly, the NAT function can be disabled.
  • Page 52 media-specific headers) that the IP attempts to send through the interface. Apply PPPoE Routed Connections PPPoE (PPP over Ethernet) provides access control in a manner similar to dial-up services using PPP. Description: A user-definable name for this connection. VPI/VCI: Enter the information provided by your ISP. NAT: The NAT (Network Address Translation) feature allows multiple users to access the Internet through a single ISP account, sharing a single IP address.
  • Page 53 Username: Enter the username provided by your ISP. You can input up to 128 alphanumeric characters (case sensitive). This is in the format of “username@ispname” instead of simply “username”. Password: Enter the password provided by your ISP. You can input up to 128 alphanumeric characters (case sensitive).
  • Page 54 Description: A user-definable name for this connection. VPI/VCI: Enter the information provided by your ISP. Encapsulation method: Select the encapsulation format, this is provided by your ISP. 4.3.2.2 DNS A Domain Name System (DNS) contains a mapping table for domain name and IP addresses.
  • Page 55 as it may provide you with an IP address for their DNS server. You must enter the DNS IP address if you set the DNS Server address on your PC to the LAN IP address of this router. 4.3.2.3 ADSL ADSL Mode: There are four modes “Open Annex Type and Follow DSLAM’s Setting”, ”Annex A”, ”Annex L”, ”Annex M”...

  • Page 56: System

    4.3.3 System There are six items within the System section: Time Zone, Remote Access, Firmware Upgrade, Backup/Restore, Restart and User Management. 4.3.3.1 Time Zone The router does not have a real time clock on board; instead, it uses the Simple Network Time Protocol (SNTP) to get the current time from an SNTP server outside your network.
  • Page 57 4.3.3.2 Remote Access To temporarily permit remote administration of the router (i.e. from outside your LAN), select a time period the router permits remote access for and click Enable. You may change other configuration options for the web administration interface using Device Management options in the Advanced section of the GUI.

  • Page 58: Backup / Restore

    4.3.3.4 Backup / Restore These functions allow you to save and backup your router’s current settings to a file on your PC, or to restore a previously saved backup. This is useful if you wish to experiment with different settings, knowing that you have a backup handy in the case of any mistakes. It is advisable to backup your router’s settings before making any significant changes to your router’s configuration.

  • Page 59: User Management

    If you wish to restart the router using the factory default settings (for example, after a firmware upgrade or if you have saved an incorrect configuration), select Factory Default Settings to reset to factory default settings. You may also reset your router to factory settings by pressing in the small Reset pinhole button on the back of your router for 10-12 seconds while the router is turned on.
  • Page 60 You can change the user’s password, whether their account is active and Valid, as well as add a comment to each user account. These options are the same when creating a user account, with the exception that once created you cannot change the username. You cannot delete the default admin account;...

  • Page 61: Firewall

    4.3.4 Firewall Firewall and Access Control Your router includes a full SPI (Stateful Packet Inspection) firewall for controlling Internet access from your LAN, as well as helping to prevent attacks from hackers. In addition to this, when using NAT (Network Address Translation) the router acts as a “natural” Internet firewall, since all PCs on your LAN use private IP addresses that cannot be directly accessed from the Internet.

  • Page 62: Packet Filter

    URL Filter: Blocks PCs on your local network from unwanted websites. A detailed explanation of each of the following five items appears in the Firewall section below: Packet Filter, MAC Address Filter, Intrusion detection, Block WAN Request and URL Filter. When using Virtual Servers (port forwarding) your PCs are exposed to the degree specified in your Virtual Server settings provided the ports specified are opened in your firewall packet filter settings.
  • Page 63 Application: User can choose they want. Outgoing Incoming: Determine whether the rule is for outgoing packets or for incoming packets. Active: Choose “Yes” to enable the rule, or choose “No” to disable the rule. Packet Type: Specify the packet type (TCP, UDP, ICMP or any) that the rule applies to. Select TCP if you wish to search for the connection-based application service on the remote server using the port number.

  • Page 64: Mac Address Filter

    Destination Port: Check the TCP or UDP packet’s destination port number(s). Schedule time: User can setup the time to use the packet filter. If the DHCP server option is enabled, you must be very careful in assigning IP addresses of a filtered private IP range to avoid conflicts because you do not know which PC in the LAN is assigned which IP address.
  • Page 65 Active: Select Yes from the drop down list box to enable MAC address filtering. Action When Matched: Select “Drop” or “Forward”. Log: Choose “Yes” if you wish to generate logs when the filer rule is applied to a packet. MAC Address: Enter the MAC addresses you wish to manage. Candidates: Choose other MAC address.

  • Page 66: Intrusion Detection

    4.3.4.3 Intrusion Detection Check “Enable” if you wish to detect intruders accessing your computer without permission. The router automatically detects and blocks a DoS (Denial of Service) attack if a user enables this function. This kind of attack is not to access confidential data on the network; instead, it aims to disrupt specific equipment or the entire network.

  • Page 67: Block Wan Request

    Intrusion Detection: Check “Enable” if you wish to detect intruders accessing your computer without permission. Alert Mail: Select this check box to use Alert Mail. Alert Mail Time: Set the time for receiving Alert mail. Your E-Mail: Set your email address. Recipient’s E-mail: Set the Recipient’s email address to which the E-<mail notification is sent.
  • Page 68 Active: Select Yes from the drop down list box to enable or disable the URL Filter feature. Always Block: Select to always check URL filter rules (i.e. at all hours of the day). Block from: Specify the time period to check URL filter rules (e.g. during work hours). Keywords Filtering: Allows blocking by specific keywords within a particular URL rather than having to specify a complete URL (e.g.
  • Page 69 Domains Filtering: Checks the domain name in URLs accessed against your list of domains to block or allow. If it matches, the URL request is sent (Trusted) or dropped (Forbidden). The checking procedure is: 1. Check the domain in the URL to determine if it is in the trusted list. If yes, the connection attempt is sent to the remote web server.

  • Page 70: Qos (Quality Of Service)

    4.3.5 QoS (Quality of Service) Quality of Service Introduction If you’ve ever found your ‘net’ speed has slowed to a crawl because another family member is using a P2P file sharing program, you’ll understand why the Quality of Service features in Billion’s routers is such a breakthrough for home users and office users.
  • Page 71 Application: A name that identifies an existing policy. Time Schedule: Scheduling your QOS policy to be applied. Direction: The traffic flow direction to be controlled by the QOS policy. There are two settings to be provided in the Router: LAN to WAN: You want to control the traffic flow from the local network to the outside world.
  • Page 72 configuration. If you want to make the change persistent in flash, choose When you press in your browser. You can use it to define a QOS policy. Controlled Traffic Flow: Specify the traffic flow you want to control. For GRE protocol, there is no need to specify the IP addresses or Application ports in this page.
  • Page 73 GRE: For PPTP VPN Connections. Assigned Data rate: Assign the data ratio for this policy to be controlled. For examples, we want to only allow 20% of the total data transfer rate for the LAN-to-WAN direction to be used for FTP server. you have ADSL LINE with 256K/bps.rate, the estimated data rate, in kbps, for this rule is 20%*256*0.9 = 46kbps.
  • Page 74 Gold service (L) Gold service (M) Gold service (H) Silver service (L) Silver service (M) Silver service (H) Bronze service (L) Bronze service (M) Bronze service (H) Local Machine IPs: The IP address values for Local LAN machines you want to control. (For IP packets from LAN to WAN, it is the source IP address.

  • Page 75: Connection Diagram

    QOS example for your Network Connection Diagram HTTP web Normal PCs browsing users Restricted PC ADSL Subscription Rate Upstream: 256 kbps Downstream: 2048 Mbps Example QOS Plan Application IP or Ports VoIP User 192.168.0.1 FTP Sever 192.168.0.100 Incoming and HTTP web VoIP Control Flow Data Rate...
  • Page 76 browsing users Example QOS Setup VoIP application Voice is latency-sensitive application. Most VoIP devices are use SIP protocol and the port number will be assigned by SIP module automatically. Better to use fixed IP address for catching VoIP packets as high priority. Going rate.
  • Page 77 Above settings will help to improve quality of your VoIP service when traffic is full loading.
  • Page 78 FTP Server Application Some of companies will setup FTP server for customer downloading or home user sharing their files by using FTP. LAN to WAN direction:...
  • Page 79 WAN to LAN direction: With above settings that help to limit utilization of upstream of FTP. Time schedule also help you to only limit utilization at day time.
  • Page 80 HTTP Web Browsing You can control the internet web browsing by specify the HTTP 80 (8080 for some proxy server). LAN to WAN direction:...
  • Page 81 WAN to LAN direction:...

  • Page 82: Virtual Server

    4.3.6 Virtual Server In TCP/IP and UDP networks a port is a 16-bit number used to identify which application program (usually a server) incoming connections should be delivered to. Some ports have numbers that are pre-assigned to them by the IANA (the Internet Assigned Numbers Authority), and these are referred to as “well-known ports”.
  • Page 83 Well-known and Registered Ports Port Number Protocol TCP & UDP TCP & UDP TCP & UDP 1503 1720 4000 7070 Item: Item number Type: Select TCP if you wish to search for connection-based application services on the remote server using the port number. Port Start &...
  • Page 84 IP Address: Enter the IP address of a specific internal server to which requests from the specified port is forwarded. Add: Click to add a new virtual server rule. Click again and the next figure appears. Edit: Check the Rule No. you wish to edit and then click “Edit”. Delete: Check the Rule No.
  • Page 85 192.168.1.2, then all incoming HTTP requests from outside users are forwarded to the local server (PC) with the IP address of 192.168.1.2. If the port is not listed as a predefined application, you need to add it manually. In addition to specifying the port number used, you also need to specify the protocol used. The protocol is determined by the particular application.

  • Page 86: Advanced

    4.3.7 Advanced Configuration options within the Advanced section are for users who wish to take advantage of the more advanced features of the router. Users who do not understand the features should not attempt to reconfigure their router, unless advised to do so by support staff.

  • Page 87: Vlan Control

    address, which changes from time to time. This dynamic IP address is the WAN IP address of the router, which is assigned to you by your ISP. You first need to register and establish an account with the Dynamic DNS provider using their website, for example http://www.dyndns.org/ There are more than 5 DDNS services supported.
  • Page 88 grouped together by VLAN technology, and broadcasts are sent to devices within the VLAN. VLAN Group Name: There are eight groups that user can setup by themselves. VLAN ID: Group name ID LAN Tagging: Tagging VLAN ID to the specific VLAN group for Ethernet interface. Ethernet port: Port name of Router Link VLAN Group to WAN connection Interface: Select the WAN connection interface that user want to link.
  • Page 89 2. After checking the box to enable VLAN function, you will check the table according to the needs as show below.

  • Page 90: Device Management

    4.3.7.4 Device Management The Device Management advanced configuration settings allow you to control your router’s security options and device monitoring features. Embedded Web Server: HTTP Port: The port number of the router’s embedded web server (for web-based configuration uses. The default value is the standard HTTP port, 80. You may specify an alternative if, for example, you are running a web server on a PC within your LAN.

  • Page 91: Snmp Version: Snmpv2C And Snmpv3

    removing the need for the user to control advanced configuration of their device. Both the user’s Operating System and the relevant application must support UPnP in addition to the router. Windows XP and Windows Me natively support UPnP (when the component is installed), and Windows 98 users may install the Internet Connection Sharing client from Windows XP in order to support UPnP.
  • Page 92 Traps supported: Cold Start, Authentication Failure. The following MIBs are supported: From RFC 1213 (MIB-II): System group Interfaces group Address Translation group IP group ICMP group TCP group UDP group Transmission SNMP group From RFC1650 (EtherLike-MIB): dot3Stats From RFC 1493 (Bridge MIB): dot1dBase group dot1dTp group dot1dStp group (if configured as spanning tree)
  • Page 93 From RFC 1473 (PPP/IP MIB): PPP IP Group From RFC 1474 (PPP/Bridge MIB): PPP Bridge Group From RFC1573 (IfMIB): ifMIBObjects Group From RFC1695 (atmMIB): atmMIBObjects From RFC 1907 (SNMPv2): only snmpSetSerialNo OID...

  • Page 94: Installing Upnp In Windows Example

    Universal Plug and Play (UPnP): UPnP offers peer-to-peer network connectivity for PCs and other network devices, along with control and data transfer between devices. UPnP offers many advantages for users running NAT routers through UPnP NAT Traversal, and on supported systems makes tasks such as port forwarding much easier by letting the application control the required settings, removing the need for the user to control advanced configuration of their device.
  • Page 95 Step 3: In the Communications window, select the Universal Plug and Play check box in the Components selection box. Step 4: Click OK to go back to the Add/Remove Programs Properties window. Click Next. Step 5: Restart the computer when prompted.
  • Page 96 Follow the steps below to install the UPnP in Windows XP. Step 1: Click Start and Control Panel. Step 2: Double-click Network Connections. Step 3: In the Network Connections window, click Advanced in the main menu and select Optional Networking Components …. The Windows Optional Networking Components Wizard window displays.
  • Page 97 Auto-discover Your UPnP-enabled Network Device Step 1: Click start and Control Panel. Double-click Network Connections. An icon displays under Internet Gateway. Step 2: Right-click the icon and select Properties. Step 3: In the Internet Connection Properties window, click Settings to see the port mappings that were automatically created.
  • Page 98 Step 4: You may edit or delete the port mappings or click Add to manually add port mappings.
  • Page 99 Step 6: Double-click on the icon to display your current Internet connection status. Web Configurator Easy Access With UPnP, you can access web-based configuration for the BiPAC 7300VGP series without first finding out the IP address of the router. This helps if you do not know the...
  • Page 100 Step 3: Select My Network Places under Other Places. Step 4: An icon describing each UPnP-enabled device shows under Local Network. Step 5: Right-click on the icon of your BiPAC 7300VGP series and select Invoke. The web configuration login screen displays.
  • Page 101 4.3.7.6 WAN IP Change Alert Send a log via Email When WAN IP is changed. Default is set to Disable.

  • Page 102: Voip

    4.3.8 VoIP VoIP enables telephone calls through existing Internet connection instead of going through the PSTN (Public Switched Telephone Network). It is not only cost-effective, especially for a long distance telephone charges, but also toll-quality voice calls over the Internet. VoIP (Voice over IP) setting could config the information account that register to the server or line configuration for different telecom environment.
  • Page 103 Local SIP Port: SIP signaling communication port number of IAD. Registrar Address: SIP Register Server IP address. Registrar Port: Port number of SIP Register Server. Proxy Address: Indicate the IP address of SIP proxy server. Proxy Port: Specify the port of the SIP proxy server on which it will listen for messages. Port 5060 is the standard port for SIP;...

  • Page 104: Line Settings

    Register to Outbound Proxy: To Register outbound Proxy, default setting is “Yes”. UDP Timeout: Timeout for an INVITE request (it is set as 100 - 3000 msec). UDP Retry Time: The number of times to send INVITE requests Session Type: Select Re-invite or Update for this function. Session Refresher: Select UAC (User agent client) or UAS (User agent server) for this function.
  • Page 106 Disabled: To disable or enable the Line setting DisplayName: The display name for the caller while making a SIP call UserID: This parameter holds the registration ID of the user with the registrar. AuthUserID: This parameter is the same as UserID. Password: User password to log into the SIP server.

  • Page 107: Call Control

    No Answer: VoIP device will forward all incoming call to the forwarding number when user is unavailable to pick up the phone Busy: VoIP device will forward all incoming call to the forwarding number when user is already on the phone talking to someone else Unconditional: VoIP device will forward all incoming call to the forwarding number.
  • Page 108 Dial Timeout: The IAD will automatically cancel a call out if the callee does not pick up the phone within the set amount of time. Ring Timeout: The IAD will automatically reject a call in if the call is not picked up within the set amount of time.

  • Page 109: Dialing Plan

    Voice Activity Detection: The voice activity detection (VAD) is a component in the DSP software that examines a caller's incoming signal and determines if the signal contains significant energy and is likely to be speech rather than a click. Default Codec: Default voice codec. ULAW size, ALAW size G.729 size, G.723 size: One RTP packet is sent out on every specified time cycle.
  • Page 110 Prefix: Numbers defined in this field will be inserted at the beginning of the dialing pattern. Maximum input length is 6 digits. Min.: Minimum digits user can key in. Max. : Maximum digits user can key in. Del.: Number of digit defined in this field will be removed from the dialing pattern. For example, if we dialed 81352109378 and the delete digit is 2, then the actual dialed number is 352109378.

  • Page 111: Address Book

    Please click the Refresh button if you want to see the updated CDR. 4.3.8.7 Address Book It is for you to store frequently used telephone numbers which you can press number setup by yourself to activate this function. For example, speed dial to phone number lists on 9, just press 9, Your router will automatically call out to number listed on entry 9.

  • Page 112: Save Configuration To Flash

    4.4 Save Configuration to Flash After changing the router’s configuration settings, you must save all of the configuration parameters to FLASH to avoid losing them after turning off or resetting your router. Click Save to write your new configuration to FLASH.

  • Page 113: Restart

    4.5 Restart Click Restart with option Current Settings to reboot your router (and restore your last saved configuration). If you wish to restart the router using the factory default settings (for example, after a firmware upgrade or if you have saved an incorrect configuration), select Factory Default Settings to reset to factory default settings.

  • Page 114: Chapter 5

    VoIP Installation Guide Please follow the setup direction described in the first section after you purchase the BiPAC 7300VGP series. And this chapter is describing how to install and use the VoIP setting. 5.1 How to obtain a personal phone number? FreeWorld Dialup 1.
  • Page 115 4. Key in your personal information and press [next] button to continue. 5. Key in your address and press [Next] to continue.
  • Page 116 6. Setting your Username and password and press [Finalize Registration] to complete registration. 7. Finish the Registration, the FWD will show your phone number in the window and please record it...

  • Page 118: Bipac 7300Vgp Voip Configuration

    5.2 BiPAC 7300VGP VoIP Configuration Please Connect to http://192.168.1.254 and configure the VoIP settings. You will see the window below when connection established.

  • Page 119: Sip Settings

    5.2.1 SIP Settings Click [VoIP SIP setting] for configuration This example is registering to FWD in the SIP setting. If you want to add other provider or edit provider rule, you can follow steps below to change it. 1. Choose the functions of [Interface] offering by Service Provider. 2.

  • Page 120: Line Settings

    5.2.2 LINE Settings Click [VoIP Line setting] for configuration 1. To enter the display name for the caller while making a SIP call 2. Input the user phone number, username and password that you registered from FreeWorld Dialup. 3. Click Dial to connection the VoIP service provider Click [Apply] button and save your configuration.

  • Page 121: How To Make A Call From Fxs To Fxo

    5.3 How to make a call from FXS to FXO This operation have to define a prefix number for opening FXO port that while user dial prefix number, the IAD will identify it and open FXO port to route into the PSTN. For example, after dialing “99”...

  • Page 122: How To Receiving An Incoming Call From Fxo Port

    5.4 How to receiving an incoming call from FXO port...

  • Page 123: General Tone Table

    5.5 General Tone Table Busy Tone American Bulgaria China France Germany Italy Japan Korea Singapore Spain Taiwan United Kingdom Ring Back Tone American Bulgaria China France Germany Italy Japan Busy Tone Frequency Frequency 2 (Hz) ( Hz) Ring Back Tone Frequency Frequency 1 ( Hz)
  • Page 124 Korea Singapore Spain Taiwan United Kingdom Dial Tone American Bulgaria China France Germany Italy Japan Korea Singapore Spain Taiwan United Kingdom Dial Tone Frequency Frequency ( Hz) (Hz) 1s/2s 1s/2s 1.5s/3s 1s/2s 1s/4s Cadence On/Off 0s/0s 0s/0s 0s/0s 0s/0s 0s/0s 0s/0s 0.25s/0.25s 0s/0s...

  • Page 125: Troubleshooting

    If your ADSL Router is not functioning properly, you can refer first to this chapter for simple troubleshooting before contacting your service provider or Billion support. This can save you time and effort but if symptoms persist, consult your service provider. Problems starting up the router None of the LEDs are on when you...

  • Page 126: Problems With The Lan Interface

    Frequent loss of ADSL linesync (disconnections). Problems with the LAN Interface Can’t ping any PCs on the LAN. Ensure that all other devices connected to the same telephone line as your router (e.g. telephones, fax machines, analogue modems) have a line filter connected between them and the wall socket (unless you are using a Central Splitter or Central Filter installed by a qualified and licensed electrician), and ensure that all line filters are correctly...
