Billion BiPAC 7300N Quick Install Manual

Adsl2/2+ broadband modem/router qos firewall wireless n draft 2 multi-port switching hub
Hide thumbs Also See for BiPAC 7300N:

Advertisement

Quick Links

Download this manual See also: User Manual
BiPAC 7300N
ADSL2/2+ Broadband Modem/Router
QoS Firewall Wireless N Draft 2
Multi-Port Switching Hub

Quick Install Guide

This guide covers only the initial
Internet set-up. Please refer to
the full User Manual on the CD-
ROM for more advanced
settings. This guide is based on
the Billion BiPAC 7300N Draft 2
ADSL2+ Wireless
Modem/Router. Screen shots in
this guide may vary slightly from
the actual router.
www.billion.uk.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the BiPAC 7300N and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Billion BiPAC 7300N

Summary of Contents for Billion BiPAC 7300N

  • Page 1: Quick Install Guide

    Internet set-up. Please refer to the full User Manual on the CD- ROM for more advanced settings. This guide is based on the Billion BiPAC 7300N Draft 2 ADSL2+ Wireless Modem/Router. Screen shots in this guide may vary slightly from the actual router.
  • Page 2 This symbol on the product or in the instructions means that your electrical and electronic equipment should be disposed at the end of its life separately from your household waste. There are separate collection systems for recycling in the EU. For more information, please contact the local authority or your retailer where you purchased the product.
  • Page 3 ADSL splitters (also called microfilters or filters) are fitted to all telephone sockets in use. 3. Connect the supplied ADSL (RJ-11) cable from the splitter/filter of your chosen telephone socket (or ADSL faceplate if you have one) to the DSL Port of your Billion 7300N Modem/Router.
  • Page 4 7. You are now ready to configure your ADSL/Broadband and Wireless connection for the Billion 7300N Modem/Router. All you need to do is to follow the instructions that follow and enter your User Name and Password as supplied by your Service Provider. No other changes should be necessary.
  • Page 5 3. From the Menu on the left select Quick Start. 4. Ensure the Connect Mode is ADSL (Recommended) and click on Continue.
  • Page 6 5. Enter your Username and Password as supplied by your Internet Service Provider in the relevant fields, and click on Continue. 6. Please wait while the router applies the new settings.
  • Page 7 7. Now click on Next to Wireless. N.B. If you do not go through the wireless setup on the Wizard, then you must click Save Config at the bottom of the page and then click Apply settings to save your username and password to Flash. 8.
  • Page 8 9. For WPA you should enter an alphanumeric password (numbers and letters) of between 8 and 64 characters in the WPA Shared Key field and click Continue. 10. Please wait while the router applies the new settings.
  • Page 9 11. This completes the wireless security configuration. 12. You should now be connected to the Internet. You can check your connection on the Status page by selecting Status from the menu on the left-hand side. 13. For advance configuration please access the manual on the CD provided.
  • Page 10 2.2 Broadband Router configuration (optional): The Ethernet Port 1 of the BiPAC 7300N at the back of the router can be configured as a WAN interface for connecting to an external broadband modem. N.B. Please note only Port 1 can be configured as a WAN interface.
  • Page 11 3. Click the Main Port tab and change it to EWAN. 4. Your page should now look like this. N.B. If you need to enter the MAC address of your PC please do so in the MAC Spoofing field and click on enable. Please check with your service provider if this is required.
  • Page 12 If this still fails then we suggest you contact your Service Provider for further advice. Billion 7300N Modem/Routers are configured with standard UK ADSL settings. Standard ADSL UK settings are VPI 0, VCI 38 and Encapsulation PPPoA VC-Mux. A small number of Service Providers do however have their own proprietary settings.
