AGA TOTAL CONTROL TC3 Installation Manual page 12

The AGA TC5 hotcupboard should arrive with the top plate in a jacked up position. This
is to allow the complete appliance to be slid onto its plinth when alongside the AGA TC3 without
the top plate clashing. The hotcupboard top plate should then be wound down to its correct
height once the appliance is in its final position.
1. Detach hotcupboard from the plinth by removing two screws and tongue bracket from plinth
(See Fig. 6). Slide hotcupboard forwards and away from rear fixing bracket (See Fig. 7).
Fig. 6
Fig. 7
12
DESN 516448
DESN 516449
