AGA TOTAL CONTROL
Model No. - TC3 & TC5
Installation
uide
REMEMBER: when replacing a part on this appliance, use only replacement parts
that you can be assured conform to the safety and performance specification that
we require. Do not use reconditioned or copy parts that have not been clearly
authorised by AGA.
PLEASE READ THESE INSTRUCTIONS BEFORE COMMENCING SITE SURVEY
OR INSTALLING THIS APPLIANCE.
IMPORTANT :
SAVE INSTRUCTIONS FOR THE LOCAL INSPECTORS USE
CUSTOMER: KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
For use in USA/Canada
3139291
11/15 EINS 516294
Advertisement
Table of Contents
Related Manuals for AGA TC3
Summary of Contents for AGA TC3
- Page 1 AGA TOTAL CONTROL Model No. - TC3 & TC5 Installation uide REMEMBER: when replacing a part on this appliance, use only replacement parts that you can be assured conform to the safety and performance specification that we require. Do not use reconditioned or copy parts that have not been clearly authorised by AGA.
-
