AGA TOTAL CONTROL
Model No's: TC3 & TC5
(ROOM VENT OPTION)
Installation
uide
REMEMBER: when replacing a part on this appliance, use only spare parts that
you can be assured conform to the safety and performance specification that we
require. Do not use reconditioned or copy parts that have not been clearly
authorised by AGA.
PLEASE READ THESE INSTRUCTIONS BEFORE COMMENCING SITE SURVEY
OR INSTALLING THIS APPLIANCE.
For use in GB and IE
11/15 EINS 516737

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TC3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AGA TC3

Summary of Contents for AGA TC3

  • Page 1 AGA TOTAL CONTROL Model No’s: TC3 & TC5 (ROOM VENT OPTION) Installation uide REMEMBER: when replacing a part on this appliance, use only spare parts that you can be assured conform to the safety and performance specification that we require. Do not use reconditioned or copy parts that have not been clearly authorised by AGA.

  • Page 2: Table Of Contents

    CLEARANCES POWER SUPPLY - AGA TC3 (ROOM VENT OPTION) POWER SUPPLY - AGA TC5 (ROOM VENT OPTION) MAINS CABLE ROUTING - AGA TC3 (ROOM VENT OPTION) 8 MAINS CABLE ROUTING - AGA TC5 (ROOM VENT OPTION) 9 HOTCUPBOARD INSTALLATION 10 - 16...

  • Page 3: Health And Safety

    Any alteration that is not approved by AGA could invalidate the approval of the appliance, operation of the warranty and could also affect your statutory rights. In the interests of safety and effective use, please read the following before using your new AGA appliance.

  • Page 4: Appliance Dimensions - Aga Tc3

    APPLIANCE DIMENSIONS - AGA TC3 (ROOM VENT OPTION) RH SIDE VIEW FRONT VIEW LH SIDE VIEW PLAN VIEW MINIMUM WALL POSITION MINIMUM WALL POSITION Fig. 1 DESN 516297 1388 1145 Cooker Dimensions When surveying for a cooker installation the actual clearance required for the ‘body’ of the appliance should be increased by 10mm beyond the figures quote above.

  • Page 5: Appliance Dimensions - Aga Tc5

    10mm beyond the figures quote above. This allows safe margin to take into account the natural dimensional variations found in major castings. In particular the width across the appliance recess could be critical. APPLIANCE WEIGHT Model: AGA Total Control (TC3) - 370 Kg Hotcupboard - 110kg...

  • Page 6: Clearances

    It is essential that the base or hearth on which the cooker stands should be level and be capable of supporting the total weight of the appliance. The base of the built-in AGA plinth must be level and sit above finished floor height for service access.

  • Page 7: Power Supply - Aga Tc3 (Room Vent Option)

    A 230v ~ 50 Hz, 3 amp fused electrical supply is required adjacent to the appliance (with the exception of the AGA TC5 and DC5 Hotcupboard with Induction Hob model, please refer to the AGA Induction Hob model instructions for the power supply requirements). External wiring to the unit must be installed using the mains cable provided, in accordance with the current regulations and any local regulations which apply.

  • Page 8: Mains Cable Routing - Aga Tc3 (Room Vent Option)

    MAINS CABLE ROUTING - AGA TC3 (ROOM VENT OPTION) MAINS CABLE FED FROM CONTROL TRAY LEFT OR RIGHT EXIT THROUGH DUCTING DEPENDENT UPON POSITION OF SUPPLY SOCKET Fig. 3 DESN 516420 THE MAINS SUPPLY CONNECT POINT MUST BE WITHIN THE ZONES SHOWN Fig.

  • Page 9: Mains Cable Routing - Aga Tc5 (Room Vent Option)

    MAINS CABLE ROUTING - AGA TC5 (ROOM VENT OPTION) HOTCUPBOARD POWER SUPPLY MAINS CABLE FED FROM CONTROL TRAY LEFT OR RIGHT EXIT THROUGH DUCTING DEPENDENT UPON POSITION OF SUPPLY Fig. 4 DESN 516562 SOCKET THE MAINS SUPPLY CONNECT POINT MUST BE WITHIN THE ZONES SHOWN Fig.

  • Page 10: Hotcupboard Installation

    NOTE: The AGA TC5 hotcupboard should arrive with the top plate in a jacked up position. This is to allow the complete appliance to be slid onto its plinth when alongside the AGA TC3 without the top plates clashing. The hotcupboard top plate should then be wound down to its correct height once the appliance is in its final position.
  • Page 11 2. Position the plinth alongside the AGA Total Control leaving no gap between the two plinths (See Fig. 7). Check with a spirit level that the plinth level is correct, and also check height differential between the hotcupboard plinth and Total Control plinth is correct (11mm). If necessary, use shims in each corner to level the plinth.
  • Page 12 4. Run a straight edge along the front of the AGA Total Control plinth, to ensure the front face of both plinths sit squarely against the straight edge. (See Fig. 9) When satisfied both plinths sit squarely, jacking screws can be tightened until they just make contact with the AGA Total Control plinth, and locking screws can now be tightened.
  • Page 13 Fig. 11 DESN 516552 7. The hotcupboard top plate is set 5mm higher than the AGA Total Control top plate. This is to prevent damage to the enamel during installation. Lower the top plate using the adjusters (See Figs. 12 and 13).
  • Page 14 8. Using the stay rod nut adjusting tool, carefully lower the top plate adjusting nuts until the top plate sits at the required height, making sure that the top sits level and matches the height of the AGA TC3. (See Fig. 13). For servicing requirement, top plate should be removed by raising adjusters approximately 5mm, the top plate can now be removed easily without causing damage to the enamelled surfaces.

  • Page 15: Handrail Connection - Aga Tc3 (Room Vent Option)

    10. Next the handrail, endcaps and handrail require assembly. Slide the handrail through the handrail brackets. AGA TC3 HANDRAIL CONNECTION Fig. 15 DESN 516880 11. On 5 oven appliances, fit allthread stud into the insert located in the one end of the...
  • Page 16 AGA Total Control plinth facia leaving no gap between. Make sure that the plinth facias are centrally located and do not overhang either appliance. (See Fig. 16) Commission the AGA Total Control, as stated in the relevant Installation Instructions and carry out functional test on each of the features of the AGA Total Control.

  • Page 17: Wiring Diagram - Aga Tc3 (Room Vent Option)

    WIRING DIAGRAM - AGA TC3 (ROOM VENT OPTION) Fig. 17...
  • Page 18 WIRING DIAGRAM - AGA TC5 (HOTCUPBOARD) COLOUR KEYS CAUTION: LABEL ALL WIRES PRIOR TO BR - BROWN DISCONNECTION, WHEN SERVICING CONTROLS BL - BLUE WIRING ERRORS CAN CAUSE IMPROPER AND GR - GREEN DANGEROUS OPERATION. OR - ORANGE BK - BLACK VERIFY PROPER OPERATION AFTER SERVICING Fig.
  • Page 20 For further advice or information contact your local AGA Specialist With AGA Rangemaster’s policy of continuous product improvement, the Company reserves the right to change specifications and make modifications to the appliance described and illustrated at any time Manufactured by...
