CS14 & CSN14 Series Converter Switches Installation and User Guide (09/09)
Switches
Fiber Port # 1 is controlled by an "F – H" switch, provided underneath port
"F" enables Full duplex to the fiber port #1
"H" enables Half duplex to the fiber port # 1
LED Indicators (Dual- front and end)
POWER:
10/100:
LK/ACT:
F/H:
Mounting option for CS14 & CSN14 Family of Switches:
Metal Mounting clips for panel mounting: included
DIN-Rail mounting option: Model # DIN-RAIL MC2 (see Section 3.4)
Rack-mount option: MC14-TRAY, see
www GarrettCom com
.
Steady On when power applied
ON = 100Mbps; OFF = 10 Mbps
Steady On for LINK (LK) with no traffic, blinking indicates port
is transmitting / receiving (ACT).
ON = full-duplex, OFF = half-duplex
.
http://www.garrettcom.com/mc_tray.htm
8
