CS14 & CSN14 Series Converter Switches Installation and User Guide (09/09)
Address buffer age-out time: 300 sec.
Packet buffers memory: 128KB, dynamically shared on all domains
Latency (not including packet time):
Path Delay Value: 50 BT on all ports
Maximum Ethernet Segment (or Domain) Lengths
10BASE-T (Unshielded twisted pair)
100BASE-TX (CAT 5 UTP)
100BASE-FX, half-duplex: (multi-mode)
100BASE-FX, full-duplex: (multi-mode)
100BASE-FX, half-duplex: (single-mode)
100BASE-FX, full-duplex: (single-mode)
100BASE-FX, full-duplex: (single-mode, long reach) - 40.0 km (131,240 ft)
10BASE-FL, Fiber optic
10BASE-FL, Single-mode Fiber optic
www GarrettCom com .
100 to 10 Mbps: <5μs
100 to 100Mbps: <4μs
.
10 to 100Mbps: <15μs
10 to 10Mbps: <13μs
2
- 100 m (328 ft)
- 100 m (328 ft)
- 412 m (1350 ft)
- 2.0 km (6,562 ft)
- 412 m (1350 ft)
- 20.0 km (65,620 ft)
- 2.0 km (6,562 ft)
- 10.0 km (32,810ft)
