Magnum14E Media Converters
Packaging:
Enclosure: High strength sheet metal.
Dimensions: 3.5 in H x 3.0 in W x 1.0 in D (8.9 cm x 7.6 cm x 2.5 cm)
**Power Supply: 2.0 in x 2.0 in x 1.5 in (5.1 cm x 5.1 cm x 3.8 cm)
Weight: 4.6 oz. (130 gr); Power Supply 1.0 lb (455 gr)
LED Indicators for the Magnum 14E (Dual, on front and on end) :
PWR
Note: Magnum 14E has Link Pass-through feature, see Section 4.5
LINK, Fiber port
.
www GarrettCom com
Indicates unit is receiving DC power.
Steady ON when both attached cable segments are operational
at their respective other ends, blinking when receiving remote
fault from the other end.
.
