Step 7—Insert the Pentium OverDrive
processor with MMX technology into the
socket.
Correctly orienting your Pentium OverDrive processor with MMX
technology in the socket is crucial to the success of your installation. The
Pentium OverDrive processor with MMX technology fits in the socket only
one way.
Orient the notch on one corner of the OverDrive processor with MMX
technology to the notch on one corner of the socket. Place the Pentium
OverDrive processor with MMX technology on the socket and align the
pins with the pin holes.
Once the pins and pin holes are properly aligned, gently insert the processor
into the socket. Don't use force to insert the processor in the socket.
Incorrectly aligning your Pentium OverDrive processor
with MMX technology can damage the processor and
your computer.
Notch
Notch
Don't apply pressure to the
center of the fan.
11
