INTEL
CELERON® PROCESSOR SPECIFICATION UPDATE
b)
causes the page table Access or Dirty (A/D) bits to be modified,
the breakpoint information for the MOVSS or POPSS will be lost. Previous Celeron processors retain this
information under these boundary conditions.
Case 3: If they occur after a MOVSS or POPSS instruction, the INT n , INTO, and INT3 instructions zero the
DR6.bi bits (bits B0 through B3), clearing pending breakpoint information, unlike previous In Celeron
processors.
Case 4: If a data breakpoint and an SMI (System Management Interrupt) occur simultaneously, the SMI will
be serviced via a call to the SMM handler, and the pending breakpoint will be lost.
Case 5: When an instruction that accesses a debug register is executed, and a breakpoint is encountered on
the instruction, the breakpoint is reported twice.
Case 6: Unlike previous versions of Intel Architecture processors, Celeron processors will not set the Bi bits
for a matching disabled breakpoint unless at least one other breakpoint is enabled.
When debugging or when developing debuggers for a Pentium III processor-based system, this
Implication:
behavior should be noted. Normal usage of the MOVSS or POPSS instructions (i.e., following them with a
MOV ESP) will not exhibit the behavior of cases 1-3. Debugging in conjunction with SMM will be limited by
case 4.
Following MOVSS and POPSS instructions with a MOV ESP instruction when using
Workaround:
breakpoints will avoid the first three cases of this erratum. No workaround has been identified for cases 4 or 5.
For the steppings affected see the Summary of Changes at the beginning of this section.
Status:
C3.
Code Fetch Matching Disabled Debug Register May Cause
Debug Exception
The bits L0-3 and G0-3 enable breakpoints local to a task and global to all tasks, respectively. If
Problem:
one of these bits is set, a breakpoint is enabled, corresponding to the addresses in the debug registers DR0-
DR3. If at least one of these breakpoints is enabled, any of these registers are disabled (i.e., L n and G n are
0), and RW n for the disabled register is 00 (indicating a breakpoint on instruction execution), normally an
instruction fetch will not cause an instruction-breakpoint fault based on a match with the address in the
disabled register(s). However, if the address in a disabled register matches the address of a code fetch which
also results in a page fault, an instruction-breakpoint fault will occur.
While debugging software, extraneous instruction-breakpoint faults may be encountered if
Implication:
breakpoint registers are not cleared when they are disabled. Debug software which does not implement a
code breakpoint handler will fail, if this occurs. If a handler is present, the fault will be serviced. Mixing data
and code may exacerbate this problem by allowing disabled data breakpoint registers to break on an
instruction fetch.
The debug handler should clear breakpoint registers before they become disabled.
Workaround:
For the steppings affected see the Summary of Changes at the beginning of this section.
Status:
26
