About This Guide; Audience; Structure - Patton electronics SMARTNODE 4110 Series Getting Started Manual

About this guide

This guide describes the SmartNode 4110 and 4520 Series hardware, installation and basic configuration. For
detailed software configuration information refer to the SmartWare Software Configuration Guide and the avail-
able Configuration Notes.

Audience

This guide is intended for the following users:
• Operators
• Installers
• Maintenance technicians

Structure

This guide contains the following chapters and appendices:
• Chapter 1 provides information about router features and capabilities
• Chapter 2 contains an overview describing router operation and applications
• Chapter 3 provides quick start installation procedures
• Chapter 4 describes getting started with the SmartNode router
• Chapter 5 contains definitions for the LED status indicators
• Chapter 6 contains information on contacting Patton technical support for assistance
• Appendix A contains specifications for the routers
• Appendix B provides cable recommendations
• Appendix C describes the router's ports and pin-outs
For best results, read the contents of this guide before you install the router.
