About this guide
This guide describes the SmartNode 4110 and 4520 Series hardware, installation and basic configuration. For
detailed software configuration information refer to the SmartWare Software Configuration Guide and the avail-
able Configuration Notes.
Audience
This guide is intended for the following users:
•
Operators
•
Installers
•
Maintenance technicians
Structure
This guide contains the following chapters and appendices:
•
Chapter 1
on page 13 provides information about router features and capabilities
•
Chapter 2
on page 25 contains an overview describing router operation and applications
•
Chapter 3
on page 33 provides quick start hardware installation procedures
•
Chapter 4
on page 45 describes getting started with the SmartNode router
•
Chapter 5
on page 53 contains definitions for the LED status indicators
•
Chapter 6
on page 59 contains information on contacting Patton technical support for assistance
•
Appendix A
on page 63 contains specifications for the routers
•
Appendix B
on page 69 provides cable recommendations
•
Appendix C
on page 75 describes the router's ports and pin-outs
•
Appendix D
on page 79 lists the factory configuration settings for SmartNode 4110 Series devices
•
Appendix E
on page 83 lists the factory configuration settings for SmartNode 4520 Series devices
•
Appendix F
on page 87 lists the tasks for installing a SmartNode 4520 or 4110 Series router
For best results, read the contents of this guide before you install the router.
