V2IU A

1. Setup the Network settings.
LAN interface IP address = 192.168.2.1
a
LAN interface subnet = 255.255.255.0
b
WAN interface IP address = 69.52.177.69
c
WAN interface subnet = 255.255.255.0
d
Default Gateway = 69.52.177.1
e
2. Setup the VoIP ALG – H323 settings
V2IU A is set to use a LAN side gatekeeper, which is 192.168.2.80
Gatekeeper Mode = LAN/Subscriber side gatekeeper
a
LAN / Subscriber side Gatekeeper Address = 192.168.2.80
b

Gatekeeper A

1. On the Path Navigator A, setup the IP configuration as
IP address = 192.168.2.80
a
Subnet mask = 255.255.255.0
b
Default Gateway = 192.168.2.1
c
2. Setup two Neighboring Gatekeeper profiles.
(Configuration – Neighboring Gatekeeper – Neighbors – Add)
In the Add Neighbor Gatekeeper dialog box, add the IP address of the
a
LAN side V2IU A ( 192.168.2.1 ). Click OK.
Note The reason for setting up the Neighboring statement with the LAN side of the V2IU
A is to enable outbound dialing from standalone endpoints on the public network.
In the Add Neighbor Gatekeeper dialog box, add the IP address of the
a
Path Navigator on the public network , GK X (67.100.100.100). Click
OK.

Gatekeeper X

1. Setup the Neighbor Gatekeeper profile.
(Configuration – Neighboring Gatekeeper – Neighbors – Add)
In the Add Neighbor Gatekeeper dialog box, add the IP address of the
WAN side V2IU A (69.52.177.69). Click OK.
Appendix
Appendix - 5
