Getting Started
Physical Installation
Warning
Desktop Installation
Caution
Wall-Mount Installation
The 4300T is designed for desktop, rack or wall-mount installation. Please
observe the following guidelines when installing the system:
•
Never assume that the AC cord is disconnected from a power source.
Always check first.
•
Always connect the AC power cord to a properly grounded AC outlet to
avoid damage to the system or injury.
Ensure that the physical location of the installation has adequate air circulation
and meets the minimum operating conditions as provided in the
environmental specifications for the system.
Secure the power supply using a fastener or nearby shelf so that it does not hang
from the power connector.
1. Remove the 4300T and accessories from the shipping container.
2. Place the 4300T on a flat, dry surface such as a desktop, shelf or tray.
3. Connect the power and network cables to the appropriate ports on the
back of the system.
To reduce the risk of fire, use only 26 AWG or larger wire (e.g. 24, 22, 20, etc.) to
connect the T1 port on your unit to an RJ-45 jack.
The 4300T can be wall-mounted using the two mounting brackets on the
bottom of the appliance. We recommend using two round or pan head screws.
2
2 - 1
