Calling up the map display

The map display is called up automatical-
ly when you start route guidance.
Without route guidance, you can call up
the map display from the main menu or
L
by a longpress on the button in sev-
eral base menus.
> Select from the main menu.
Map
The map display will then appear and, if
GPS reception is available, will show your
current position.
If route guidance is already active, the
map will be displayed with route guid-
ance.

Structure of the map display

The structure depends on the settings
made in "Map display" on page 38 and
whether route guidance is active or not.

Map display without route guidance

3
4
If the navigation is not active, almost the
whole area of the display will be taken up
by the map.
Speed limit on the road currently be-
1
ing driven on (display not available
for all roads), signs for the driver
alerts will also be displayed
Number of satellites currently being
2
received
Vehicle position
3
Current road
4

Map display with route guidance

10
9
8
1
7
Road signs, which you should follow
1
Speed limit on the road currently be-
2
ing driven on (display not available
2
for all roads)
Driver alerts
3
Number of satellites currently being
4
received
Display of TMC status
5
Vehicle position
6
Current road
7
or
Traffic lane recommendation (only
appears on some multi-lane roads;
green arrows = recommended lanes)
