About Licensing

The ADMM needs to be enabled with a license key, which depends on the MAC address of
some IP DECT base stations in the DECT system. The license key needs to be entered /
administered via the ADMM web administration interface.
There are a sets of licenses with additional upgrade licenses .
License for 1 IP DECT base station
●
License for 2 IP DECT base stations
●
License for 3 to 5 IP DECT base stations
●
License for more than 5 IP DECT base stations
●
As mentioned above the license key depends on the MAC addresses of some IP DECT base
stations of the DECT system (License-IP DECT base stations). Each IP DECT base station can
be an License-IP DECT base station independently where the IP DECT base station is located.
The number of IP DECT base station MAC addresses encoded in the license depends on the
size of the DECT installation.
System size
(# of IP DECT base
stations)
1
2
3 to 5
6 or more (6+)
Additionally to the MAC addresses the PARK (Portable Access Rights Key), which identifies the
DECT installation, is also by part of the license. Because a DECT system can only be operated
with a valid PARK, a DECT installation without a license will be inactive on the DECT site.
An IP DECT system is operational, if it set up with a license and the IP DECT base stations,
which are encoded in the license are part of the system so that the ADMM can communicate
with these License-IP DECT base stations.
Number of IP DECT base station MAC addresses
encoded in the license (License-IP DECT base
stations)
1
2
3
3
