NAT/Route mode installation

Configuring ping servers

FortiGate-800 Installation and Configuration Guide
Figure 9: Example multiple Internet connection configuration
8
External
1.1.1.2
Gateway #1: 1.1.1.1
ISP1
External Network #1
100.100.100.0
Use the following procedure to make gateway 1 the ping server for the external
interface and gateway 2 the ping server for the DMZ interface.
1 Go to System > Network > Interface.
2 For the external interface, select Modify
• Ping Server: 1.1.1.1
• Select Enable Ping Server
• Select OK
3 For the DMZ interface, select Modify
• Ping Server: 2.2.2.1
• Select Enable Ping Server
• Select OK
Configuration example: Multiple connections to the Internet
Internal Network
192.168.1.0
Internal
192.168.1.99
I N T E R N A L E X T E R N A L D M Z HA 1 2 3
Esc Enter
P W R
FortiGate-800
Gateway #2: 2.2.2.1
External Network #2
Internet
4 CONSOLE USB
Port3
2.2.2.2
ISP2
200.200.200.0
.
.
