Getting started

Powering on

FortiGate-800 Installation and Configuration Guide

Power requirements

• Power dissipation: 300 W (max)
• AC input voltage: 100 to 240 VAC
• AC input current: 6 A
• Frequency: 50 to 60 Hz

Environmental specifications

• Operating temperature: 41 to 95°F (5 to 35°C)
• Storage temperature: -4 to 176°F (-20 to 80°C)
• Humidity: 10 to 90% non-condensing
To power on the FortiGate-800 unit
1 Make sure that the power switch on the back is turned off.
2 Connect the power cable to the power connection on the back of the FortiGate unit.
3 Connect the power cable to a power outlet.
4 Turn on the power switch.
After a few seconds, SYSTEM STARTING appears
on the LCD.
MAIN MENU appears on the LCD when the system
is running.
Table 1: FortiGate-500 LED indicators
LED
Power
Internal
External
DMZ
HA
1 to 4
State Description
Green The FortiGate unit is powered on.
Off The FortiGate unit is powered off.
Amber The correct cable is in use and the connected equipment has
power.
Flashing Network activity at this interface.
amber
Green The interface is connected. Internal, External, DMZ and HA
connect at up to 1000 Mbps. Interfaces 1, 2, 3 and 4 connect at
up to 100 Mbps.
Off No link established.
Powering on
27
