Configuring interfaces

Adding a secondary IP address to an interface

Adding a ping server to an interface

142
7 Select Apply.
The FortiGate unit attempts to contact the PPPoE server from the interface to set the
IP address, netmask, default gateway IP address, and DNS server IP addresses.
8 Select Status: to refresh the addressing mode status message. Possible messages:
initializing No activity
connecting The FortiGate unit is attempting to connect to the DHCP server.
connected The FortiGate unit retrieves an IP address, netmask, and other settings from
the PPPoE server.
failed The FortiGate unit was unable to retrieve an IP address and other
information from the PPPoE server.
9 Select OK.
You can use the CLI to add a secondary IP address to any FortiGate interface. The
secondary IP address cannot be the same as the primary IP address but it can be on
the same subnet.
To add a secondary IP address from the CLI enter the command:
set system interface <intf_str> config secip <second_ip>
<netmask_ip>
You can also configure management access and add a ping server to the secondary
IP address.
set system interface <intf_str> config secallowaccess ping
https ssh snmp http telnet
set system interface <intf_str> config secgwdetect enable
Add a ping server to an interface if you want the FortiGate unit to confirm connectivity
with the next hop router on the network connected to the interface. Adding a ping
server is required for routing failover. See
routing table" on page
To add a ping server to an interface
1 Go to System > Network > Interface.
2 Choose an interface and select Modify
3 Set Ping Server to the IP address of the next hop router on the network connected to
the interface.
4 Select the Enable check box.
The FortiGate unit uses dead gateway detection to ping the Ping Server IP address to
make sure that the FortiGate unit can connect to this IP address. To configure dead
gateway detection, see
page 171.
5 Select OK to save the changes.
"Adding destination-based routes to the
154.
.
"Modifying the Dead Gateway Detection settings" on
