CyberParallel Dual User's Manual
2. Unplug the power cord from the back of the computer.
3. Remove the computer's cover.
4. Select an available 32-bit PCI slot for the new board.
If you intend to install the DB25 parallel port
connector bracket, select an I/O expansion slot with
an adjacent slot for installing the connector bracket.
5. Remove the selected slot brackets by unscrewing the hold-
ing screws and sliding them out. Save the screws for se-
curing the CyberParallel Dual and the connector bracket
after they are installed.
6. To install the CyberParallel Dual, carefully align the board's
bus connector with the selected expansion slot on the
motherboard. Push the board down firmly, but gently,
until it is well seated.
7. To install the DB25 parallel port connector bracket,
carefully slide it into the slot where the slot bracket had
been removed.
2-2
Fig. 2-1. Remove the Slot Bracket
NOTE
