Features And Specifications; Front View; Rear View; Operators Manual - Microcom 400 Operator's Manual

Features and Specifications

LABEL SUPPLY SHAFT
TOP COVER
POWER CORD
FRONT PANEL LED
FRONT PANEL
SERIAL PORT
LINE GUIDE IDLER
LINE GUIDE SHAFT
PAPER LINE GUIDES
6
LABEL SUPPORT RACKS
LABEL FEED AND LINE FEED BUTTON
Microcom 400 Printer

Front View

Figure 1
LINE GUIDE ADJUSTMENT KNOB
THUMB NUTS
REAR PANEL
Microcom 400 Printer

Rear View

Figure 2
Chapter 1
PUSH TO LIFT HEAD LEVER
PEEL EDGE
DRIVE ROLLER
PINCH ROLLER
PINCH ROLLER RELEASE LEVER (OPTIONAL)
LABEL DIAPHRAGMS
POWER SWITCH
POWER CORD

400 Operators Manual
