Programming Flash Timing - Telematrix Spectrum Plus SP750 User Manual

Programming Flash Timing

(Administrator)
Flash timing can be programmed for different timing options listed below.
1. Press and hold the "STORE" key for 6-seconds to enter set up.
2. Press the "STORE" key multiple times until the LCD display reads "FLASH TIME
SET".
3. Enter the flash timing to be stored into memory using the keypad by pressing
the following keys on the keypad in the order shown. The keypad entry will be
displayed on the LCD Screen.
For 100mS
For 200mS
For 300mS
For 400mS
For 500mS
For 600mS
For 700mS
For 800mS
For 900mS
For 1000mS
4. To exit the program mode, press "DISC" or continue to the end of program-
ming by pressing the "STORE" key multiple times until the display reads "All
Setup OK".
5. To confirm the flash timing programmed in memory, repeat the Administrator
programming sequence to see flash timing display.
Programming Example for 100mS
Press "STORE" for 6 seconds, Press "STORE" again until LCD
reads " "FLASH TIME SET". Enter digits "100" from the keypad.
Press "STORE" to enter the timing into memory.
!
press "1" "0" "0" on the keypad.
press "2" "0" "0" on the keypad.
press "3" "0" "0" on the keypad.
press "4" "0" "0" on the keypad.
press "5" "0" "0" on the keypad.
press "6" "0" "0" on the keypad.
press "7" "0" "0" on the keypad.
press "8" "0" "0" on the keypad.
press "9" "0" "0" on the keypad.
press "1" "0" "0" "0" on the keypad.
NOTE: The Flash Timing factory default is 600mS
!
24
Note: Programming can
only be performed when
the phone is on-hook
