Telematrix Spectrum Plus SP750 User Manual page 31

Programming Procedure for Spectrum PLUS
(Administrator) (Manual Entry of Characters)
The Spectrum PLUS
are convenient for dialing frequently used telephone numbers. This feature is under
Administrative control so user changes do not occur.
•
Speed dial programming must be done with the telephone plugged into the telephone line and power adapter.
•
Programming can be performed with the telephone on-hook only.
•
A maximum of 32-digits can be entered into ENTER NUMBER and 32-characters into ENTER NAME.
ENTER NUMBER
ENTER NAME
To Program Speed Dial Locations
1. Press and hold the "STORE" key quickly.
The words "SET UP MONTH: 01" will appear
(figure 1).
2. Next, press the speed dial location key
where the desired location will be. The
display will read "Mxx NO CONTENT". If the
display shows a record, then there is a
stored name and number in that location
(figure 2).
3. Press the "STORE" key again and the dis-
play will read "ENTER NUMBER" (figure 3).
4. Using the dial pad, enter the number. Note
that the local area code is not required if
AREA CODE is pre-programmed into mem-
ory.
5. After entering
"STORE" key. The display will read "ENTER
NAME" (figure 4).
6. Using the keypad, enter the name associated
with the number being programmed and in-
clude the Flash, and/or Pause, when needed.
7. Press the "STORE" key to store the entry.
8. Program other speed dial locations, repeat 2
to 7.
9. To exit the program mode, press "DISC".
TM
Telephone has eleven (11) one-touch speed dial locations that
Set up speed dial mem-
ory locations with name
and number entries.
Check verifies correct
entry.
the number, press
TM
Speed Dial Features
SET UP MONTH: 01
M01 NO CONTENT
the
ENTER NUMBER
31
12/01
PM
Figure 1
12/01
PM
Figure 2
12/01
PM
Figure 3
12/01
PM
ENTER NAME
Figure 4
