1 Data Port .....................................
2 Line Jack ................................................
3. Headset Jacks .............................
4 Handset Jack ...............................
5. Power Adapter Receptacle .................
6 Low Voltage MW Switch .....................
7 Hold Key Switch .................................
8 Elevation Stand Lock ...........................
Convenient port to connect a computer,
modem, fax or answering device.
Modular receptacle for connecting the
line cord.
Convenient RJ port or 2.5mm coaxial port used
to connect an optional headset.
Connection for handset coil cord.
For optional coaxial power adapter.
Used to select LED Message Waiting On or OFF.
Used to select standard line hold or
programmable system hold.
Used to "lock" the elevation stand.
9
