Programming Flash Timing - Telematrix Spectrum Plus SP300 User Manual

Spectrum plus series single line feature telephone

Hide thumbs Also See for Spectrum Plus SP300:

Table of Contents

Programming Flash Timing

Flash timing can be programmed for different timing options listed below.

1. Position the handset in the Off-Hook position (lift the handset).

2. Press the "STORE" key once.

3. Press "*" key for 3-seconds until an alert sound is heard.

4. Press the following keys on the keypad in the order shown:

4. Place the handset cradle to the On-Hook position.

Go Off hook with handset, press "store" once, then "*" for

3-seconds to enter set up mode, then "1", then "#". Place

the handset into cradle to the on-hook Position.

For 100mS press "1", then "#".

For 200mS press "2", then "#".

For 300mS press "3", then "#".

For 400mS press "4", then "#".

For 500mS press "5", then "#".

For 600mS press "6", then "#".

For 700mS press "7", then "#".

For 800mS press "8", then "#".

For 900mS press "9", then "#".

For 1000mS press "0", then "#".

Programming Example for 100mS

NOTE: The Flash Timing factory default is 600mS
