3. Specifications

3. Specifications

3.1. Operating Environment

Parameter
Ambient Operating Temperature
Ambient Relative Humidity
Ambient Storage Temperature
Operating Altitude
Table 3.1. Operating Environment

3.2. Power Supply Specifications

Power
Supply Type
12 – 24 VDC
24 VDC
48 VDC
HI (125/250 VDC)
HI (110/230 VAC)
a
(T) denotes time-delay fuse
b
This is the same power supply for both AC and DC.
Table 3.2. RS900G Power Supply Specifications

3.3. Failsafe Relay Specifications

Table 3.3. Failsafe Relay Specifications
• Resistive Load.
• For Class-2 circuits only.

3.4. Twisted Pair Data Port Specifications

Data Port
10/100 Mbps
Table 3.4. Twisted Pair Data Port Specifications
RuggedCom® RuggedSwitch™
Minimum Input Maximum Input
10 VDC
18 VDC
36 VDC
b
88 VDC
b
85 VAC
Parameter
Max Switching Voltage
Rated Switching Current
Media
Cat 5 UTP or STP
Range
-40 to 85°C
5% to 95%
-40 to 85°C
0 to 15240m (0 to 50000 ft)
Fuse Rating
36 VDC 3.15A (T)
36 VDC 3.15A (T)
72VDC 3.15A (T)
300 VDC
3.15A (T)
265 VAC
Distance
16
Comments
Ambient Temperature as measured
from a 30cm radius surrounding the
center of the RS900G enclosure.
Non-condensing
Over temperature range of -40 to 85°C
Isolation
a
1.5 kV DC
a
1.5 kV DC
a
1.5 kV DC
a
4 kV AC 5.5 kV DC
Value
30VAC, 80VDC
0.3A @ 30VAC
1A @ 30VDC, 0.3A @ 80VDC
Connector Type
100m
RS900G Installation Guide Rev 107
Maximum Power
Consumption
10W
RJ45
