3. Specifications
3.6. Physical Dimensions
Figure 3.1. RS900G Physical Dimensions
Parameter
Dimensions
Weight
Enclosure
Table 3.6. Physical Specifications
RuggedCom® RuggedSwitch™
Value
7.4 × 2.6 × 5.0 inches
(187.96 × 66.04 × 127.0 mm)
2.7 lbs (1.2 kg)
20 AWG Galvanized Steel
18
Comments
(Length × Width × Depth
RS900G Installation Guide Rev 107
