Unit FiberAlert – Enables/disables FiberAlert and LinkLoss functionality on the unit.
The settings include:
• No FiberAlert Or LinkLoss Enabled
• FXLinkLoss Only, Enabled
• TXLinkLoss Only, Enabled
• FiberAlert Plus FXLinkLoss Enabled
• FiberAlert Plus TXLinkLoss Enabled
• TXLinkLoss Plus FXLinkLoss Enabled
• TXLinkLoss + FXLinkLoss + FiberAlert Enabled
• FiberAlert Only
FiberAlert is not offered on the all-copper (RJ-45) version of the iMcV-FiberLinX-II.
Unit LoopBack – Enables/disables Loopback functionality on the unit. The settings
include the following:
• No LoopBack, Normal Traffic Mode
• LoopBack Enabled
• LoopBack, Src/Dest Address Swap
• LoopBack, Address Swap, Clear Multicast bit
• No Learning on OPTICS (or UPLINK) or DATA Ports
Unit Max FrameSz – Enter the maximum frame size on the unit by using the number
keys.
• No VLAN–1518
• VLAN Tag–1522
• Oversized frames–1536
• Oversized frames–1916
802.1p Base Pri – Set the threshold between low and high priority on the unit. For
example, when the Base VLAN Priority is set to 4, priority settings of 0 through 3 are
low priority and settings of 4 through 7 are high priority. When the Base VLAN
Priority is set to 3, priority settings of 0 through 2 are low priority and priority settings
of 3 through 7 are high priority.
BrdCast Max Rate – Set the Broadcast Storm protection. Valid values are 0-20%
where 0% disables Broadcast Storm protection. The setting is the percentage of line
speed where broadcast frames will be dropped. For example, if the setting is 1% and
the unit detects that broadcast traffic is exceeding 1% of the line speed then the unit
will discard broadcast frames. The suggested setting is 1%.
NOTE
36
