Basic Device Configuration

After running through an initial self test, the screen will display the following message:
Press <Enter> for Device Configuration. Press Enter open the main configuration
screen:
Saved Values. <These values will be active after reboot>
IP Address -
Subnet Mask - 255.0.0.0
Default Gateway - 000.000.000.000
Server IP Addr - 000.000.000.000
New Prom File - filename
Current Values. <These values are in use now>
IP Address -
Subnet Mask - 255.0.0.0
Default Gateway - 000.000.000.000
Server IP Addr - 000.000.000.000
New Prom File - filename
Community String: public
Press I to enter new saved parameter values. Press
Press T to enter new Trap Destination. Press
Press C to enter new Community String. Press
Press E to End session. Type
Press SpaceBar for additional commands.
This screen contains the following information and options:
Saved and Current Values
Saved values display the changes made during the current session and current values
display the values currently in use:
• IP Address (IP address of SNMP agent)
• Subnet Mask (mask to define IP subnet to which agent is connected)
• Default Gateway (default router for IP traffic outside of the subnet)
• Server IP Address (TFTP server)
• New Prom File (TFTP new file name)
Command List
I = Enter new Saved Parameter Values
P = Change the Password*
T = Enter new Trap Destinations
K = Remove All Trap Destinations
C = Create SNMP Community Strings
U = Delete All SNMP Community Strings
E = End the session*
Reboot = Reboot the unit (may result in short data loss)
D = Enable or disable DHCP
Space Bar = Opens the device specific configuration options screen.
* Individuals with User-level rights can only view port status and port settings, change
their password, end a session, and reboot the unit.
10.10.10.10
DHCP is not active
10.10.10.10
Access: r/w
K
U
REBOOT to reboot unit. Press
23
P to change Password.
to remove ALL Trap Destinations.
to remove ALL Community Strings.
D for DHCP On/Off.
