Installing Decorating Logs; Hole On Log 2, With The Other End Of Log 5 Placed Where Marked. (See Fig - Procom SFE23RE Series Installation Instructions And Owner's Manual

1 2
4 5
FIG 1
4 1
FIG 3
2.Insert the pin on one end of log 4 to the recessed
hole on log 1, with the other end of log 4 placed
where marked. (See FIG 3).
6 4 1
FIG 5
4.Insert the pin on log 6 to the recessed hole on
log 4, and place log 6 as figure shows. (See FIG 5).

Installing decorating logs

Installing logs for SFE33RE Series:
3
6
2 3
2 5 3
1.Place log 1, log 2 and log 3 into the correspond-
ing holes on grate. (See FIG 2).
4
3.Insert the pin on one end of log 5 to the recessed
hole on log 2, with the other end of log 5 placed
where marked. (See FIG 4).
4
5
1 2 3
FIG 2
1 2 5 3
FIG 4
