Upgrading The Computer
6
Figure 6 - 8
3.5" HDD Assembly
Removal
6 - 10 Upgrading the Hard Disk Drive/SSD

Removing the 3.5" (88.9mm) HDD

1. Remove the battery and rear cover (see pages
2. The hard disk is located at point
3. Remove screws -
2
4. Slide the HDD assembly in the direction of arrow
5. Life the HDD assembly
1
6 - 3
.
1
from the hard disk bracket.
5
out of the computer.
7
6
& 6 - 5).
.
6
2 3
4 5
7
