Upgrading the System Memory (RAM)

Figure 10
RAM Module
The computer has two memory sockets for 204 pin Small Outline Dual In-line (SO-DIMM) DDRIII (DDR3) type mem-
Removal
ory modules (see Memory
a. Locate the RAM.
The total memory size is automatically detected by the POST routine once you turn on your computer.
b. Pull the latches to re-
lease the RAM mod-
1. Remove the battery
ule.
2. The RAM is located at point
c. Remove the RAM
3. Gently pull the two release latches on the sides of the memory socket in the direction indicated by the arrows (
module.
&
4. The RAM module
Single Memory
a.
Module Installation
If your computer has a
single memory module,
then insert the module
into the Channel 0
(JDIMM_1) socket. In
this case this is the up-
per memory socket (the
socket furthest from the
mainboard) as shown in
b
Figure 10 .
b.

D. RAM Module
2 - 14 Upgrading the System Memory (RAM)
page 1 - 2 for details of supported module types).
(page 2 - 5) and rear top cover
( Figure 10a
A
) in Figure 10b.
C
will pop-up ( Figure 10c
D 6
B
C
(page 2 - 7).
) .
) , and you can remove it (see over).
c.
A
Contact Warning
Be careful not to touch the metal pins on the module's connecting edge. Even
the cleanest hands have oils which can attract particles, and degrade the mod-
ule's performance.
D

B
