ATA Mode Configuration

If you wish to configure your hard disk(s) in ATA mode, then see the instructions on following next pages.
You will need an external floppy drive attached to install the driver ATA driver when setting up Windows.
4
4 - 2 ATA Mode Configuration
Jumper Settings for Two Parallel ATA Hard Disks
If you are using Parallel ATA (PATA) hard disk drives. then set the jumper on the
Slave hard disk to the Cable Select option in order for the system to recognize the
disks (see your hard disk manual or the information printed on the hard disk itself
for details on the jumper settings). The Slave disk will automatically be in the upper
slot of the hard disk bracket, the Master will be in the lower slot (as defined by the
hard disk cable).
See Chapter 6: "Upgrading the Hard Disk Drive(s)" on page 6 - 4
tions on removing the hard disk.
for instruc-
