Introduction

System Specifications

Processor
Intel® Core i7-3960X (3.30GHz)
15MB L3 Cache, 32nm (32 Nanometer),
DDR3-1600MHz, TDP 130W
Intel® Core i7-3820X (3.20GHz)
12MB L3 Cache, 32nm (32 Nanometer),
DDR3-1600MHz, TDP 130W
Intel® Core i7-3930X (3.20GHz)
12MB L3 Cache, 32nm (32 Nanometer),
DDR3-1600MHz, TDP 130W
Core Logic
Intel® X79 Express Chipset
Display
17.3" (46.94cm) FHD (1920 * 1080) 16:9
Backlit Panel
For P270WM3 with 3D Support
Built-in 3D IR Emitter
One nVIDIA® 3D Vision™ 2 Shutter Glasses
Kit
Memory
Four Channel DDRIII (DDR3)
Four 204 Pin SO-DIMM Sockets Supporting
DDRIII (DDR3) 1333/1600 MHz Memory
Modules (real operational frequency depends
on the FSB of the processor)
Memory Expandable up to 16GB
Compatible with 2GB or 4GB Modules
1 - 2 System Specifications
Video Adapter
nVIDIA® GeForce GTX 580M PCIe * 16
Video Card
2GB GDDR5 Video RAM On Board
Supports Microsoft DirectX® 11.0
MXM3.0 Type B
Supports DisplayPort 1.1a
nVIDIA PhysX™
GeForce CUDA™ Technology
Supports nVIDIA® SLI Technology
===============================
For P270WM3 with 3D Support
Supports 3DTV Play™
===============================
For P270WM Only:
nVIDIA® Quadro 5010M PCIe * 16 Video
Card
4GB GDDR5 Video RAM On Board
Supports Microsoft DirectX® 11.0
MXM3.0 Type B
Supports DisplayPort 1.1a
nVIDIA PhysX™
GeForce CUDA™ Technology
Supports OpenGL 4.1
BIOS
One 64Mb SPI Flash ROM
AMI BIOS
Storage
Up to three (Factory Option) Changeable
2.5" 9.5 mm (h) SATA (Serial) Hard Disk
Drives supporting RAID level 0/1/5
One 12.7 mm Super Multi/Blu-Ray Combo/
Blu-Ray Writer SATA Optical Device Drive
(Factory Option)
Audio
High Definition Audio
S/PDIF Digital Output
Built-In Microphone
5 Built-In Speakers
One built-in 3W Sub woofer
THX® TruStudio Pro Surround Sound
External 7.1CH Audio output supported by
headphone, microphone, S/PDIF & Line-In
Jack
Keyboard & Pointing Device
Full Size Winkey Illuminated Keyboard with
Numeric Keypad
Built-In TouchPad (with Multi Gesture
Functionality)
Six Touch Sensor Instant Keys (Volume Up,
Volume Down, Mute, WLAN, Bluetooth & PC
Camera)
W/A/S/D Gaming Keys
