Card Reader
Embedded Multi-In-1 Card Reader
- MMC / RSMMC
- SD / Mini SD / SDHC / SDXC
- MS / MS Pro / MS Duo
Note: Some of these cards require PC
adapters that are usually supplied with the
cards.
Slots
One ExpressCard™ (34/54) Slot
One Mini Card Slot for WLAN & Bluetooth
Combo Half Mini-Card Module with PCIe &
USB Interface
Interface
Three USB 3.0 Ports (Including one AC/DC
Powered USB/ eSATA Combo Port)
Two USB 2.0 Ports
One eSATA Port (SATA Interface, C/DC
Powered USB 3.0 Combo)
One Mini-IEEE1394b Port
One DisplayPort (Version is Video Controller
Dependant)
One DVI-I Out Port (Single Link)
One HDMI (High-Definition Multimedia
Interface) 1.4a Out Port (with HDCP Support)
One Headphone/Speaker-Out Jack
One Microphone-In Jack
One S/PDIF Out Jack
One Line-In Jack
One RJ-45 LAN Jack
One DC-In Jack
Communication
Built-In 10/100/1000 Base-TX Ethernet LAN
Intel® Centrino® Ultimate-N 6300 3*3 (802.11
a/g/n) Half Mini-Card PCIe WLAN Module (Fac-
tory Option)
Intel® Centrino® Advanced-N 6230 2*2
(802.11 a/g/n) Half Mini-Card PCIe WLAN +
Bluetooth V3.0+HS Combo Module (Factory
Option)
802.11b/g/n Wireless LAN Half Mini-Card
Module (Factory Option)
Combo WLAN (802.11b/g/n) and Bluetooth
v3.0 Half Mini-Card Module (Factory Option)
Bluetooth 2.1 + EDR (Enhanced Data Rate)
Module (Factory Option)
2.0M Pixel FHD PC Video Camera Module
(Factory Option)
2.0M Pixel PC Video Camera Module
(Factory Option)
Security
Security (Kensington® Type) Lock Slot
BIOS Password
Fingerprint Reader Module
Trusted Platform Module 1.2
Operating System
Windows® 7 with Service Pack 1
Design Feature
Alloy Plate
Power Management
Supports Wake on LAN
Supports Wake on USB
Power
Full Range AC/DC Adapter – AC in 100 -
240V, 50 - 60Hz DC Output 20V, 15A (300
Watts)
Removable Polymer Smart Li-Ion 78.44WH
Battery Pack
Power Converter Box (Factory Option)
Environmental Spec
Temperature
° °
Operating: 10 C - 35 C
Non-Operating: -20°C - 60°C
Relative Humidity
Operating: 20% - 80%
Non-Operating: 10% - 90%
Physical Dimensions & Weight
419mm (w) * 286mm (d) * 57.9mm - 62.1mm (h)
5.5kg with Single VGA Card, Battery and
ODD
