Removing the System Memory

1. Remove the LCD back cover
2. The memory sockets will be visible at point
3. For each module you want to replace, gently pull the latches
module.
4. The module will pop-up, and you can remove it.
4
5. Insert a new module holding it at about a 30° angle and fit the connectors firmly into the memory slot.
a.
1
(page 2 - 6).
on the mainboard.
1
2
b.
3
c.
and toward the sides of the socket to release the
3
4
Disassembly
Figure 2 - 3
Memory Removal
Sequence
a. Locate the memory
sockets.
b. Pull the latch(es) on
the memory sockets to
release the module(s).
c. When the
pops up, lift it out.
2
4. Memory module(s)
Contact Warning
Be careful not to touch
the metal pins on the
module's connecting
edge. Even the clean-
est hands have oils
which can attract parti-
cles, and degrade the
module's
mance.
Removing the System Memory 2 - 7
module
perfor-
