Removing the Hard Disk Drive Assembly

1. Turn OFF the computer and turn it around so that you may comfortably access the left side.
2. Remove screw from the HDD Bay
1
3. Carefully pull the HDD assembly out from the bay and disconnect the IDE cable
4. Turn the assembly over and remove screws (
5. Remove screws - and separate the hard disk
10 15
6. Insert the new hard disk, and reverse the removal procedures to install the new hard disk.
a.
2
1
d.
9
5
6
7
8
.
2
- ) holding the assembly to the bay cover
5 8
and case .
16 17
b.
e.
17
13
14
, and power cable .
3 4
9 .
c.
3
4
10
11
12
16
15
Removing the Hard Disk Drive Assembly 2 - 5
Disassembly
Figure 2 - 1
Hard Disk Removal
Sequence
a. Remove the screw
from the HDD Bay.
b. Slide the HDD assem-
bly in the direction of
the arrow.
c. Disconnect the IDE
and power cables.
d. Remove the screws
from the assembly.
e. Remove the screws
and separate the HDD
from the case.
9. HDD Bay Cover
16. HDD
17. HDD case
• 11 Screws
