EUROCOM L295U Series Service Manual page 12

Introduction
Feature
Video
Audio
Interface
I/O Chip
PC Card Sockets
1 - 4 System Specifications L295U/L297U
Specification - L295U
Video RAM - Shared Memory Architecture (SMA)
Supporting DDR Video Shared Memory up to 64MB
2D Hardware Accelerator (for block level transfers of data integrating an extensive set of instructions for 3D)
The system allocates or "shares" a portion of system memory for video use. See "Dynamic
Video Memory Technology" on page 3 - 2 for information on the system allocated video
memory, and "Share Memory (Main Menu)" on page 5 - 8
urable options.
™
SoundBlaster
Three Audio Jacks for Headphone-Out, Line-In, and Microphone-In
One Serial Port (16550A Compatible, 9 Pin Shell, up to 115Kbps)
One Parallel Port (25pin Shell, SPP/Bi-Direction/ECP/EPP Mode Support)
One External Monitor (VGA) Port (15-pin D-sub)
Two PS/2 Ports (Keyboard & Mouse)
Three Audio Jacks For Headphone-out, Line-in, and Microphone-in
One RJ-45 Jack for 100M/10M Ethernet LAN
One RJ-11 Port for Modem (optional)
One Mini-PCI /IF IEEE 1394 Module (optional) - Enables IEEE 1394 Port (6 Pin Un-Powered)
Supports Two Type II Slots or One Type III PCMCIA Slot (Cardbus Support)
Specification - L297U
865-GV Integrated Chipset
Video Memory
for information on user config-
AC97' Compatible
™
and Windows Sound System Compatible
Two Built-In Speakers (3W)
Four USB 2.0 Ports
Winbond W83627HF
