Disassembly

Removing the Floppy Disk Drive Assembly

Figure 2 - 8
Floppy Disk Drive
1. Remove the LCD back cover
Assembly
2. Remove screws
Removal
3. Carefully disconnect the floppy disk drive ribbon cable at point
Sequence
4. Lift the floppy disk drive assembly
a. Remove the screws
from the FDD assem-
bly and disconnect the
FDD ribbon cable.
b. Lift the FDD assembly
off the board.
6. FDD Assembly
• 4 Screws
2 - 12 Removing the Floppy Disk Drive Assembly
(page 2 - 6).
- from the floppy disk drive assembly.
1 4
off the mainboard.
6
a.
2
1 5
b.
.
5
3
4
6
