Disassembly
Removing the CD Device Assembly (L295U Series)
Figure 2 - 10
L295U CD Device
1. Remove the LCD back cover
Assembly
2. Remove screws
Removal
3. Remove the CD Device
Sequence
a. Remove the screws
a.
and disconnect the
cable.
b. Remove the CD De-
vice.
5. CD Device
• 3 Screws
2 - 14 Removing the CD Device Assembly (L295U Series)
(page 2 -
-
, and disconnect cable
1
3
5
.
1
4
2
6).
, from the CD device.
4
b.
3
5
