Removing The I/O Bracket - EUROCOM L295U Series Service Manual

Disassembly

Removing the I/O Bracket

Figure 2 - 6
I/O Bracket
1. Remove the LCD back cover
Removal
2. Remove the standard screws
Sequence
type screws
3. Carefully ease the I/O bracket
a. Remove the screws
from the I/O bracket.
b. Lift the I/O bracket up
off the mainboard.
10. I/O bracket
9 Screws
2 - 10 Removing the I/O Bracket
(page 2 - 6).
- , and use long-nosed pliers or a nutdriver to remove the hex socket connector
1 3
- .
4 9
10 off the mainboard.
a.
1 2
b.
4 5 8 9
6 7
3
10
