External Locator - Rear View - EUROCOM L295U Series Service Manual

Introduction

External Locator - Rear View

Figure 1 - 3
Rear View
1. Carrying Handle
2. Headphone-Out
Jack
3. Line-In Jack
4. Microphone-In
Jack
5. RJ-45 LAN Jack
6. RJ-11 Phone
Jack
7. Dual USB Ports
8. Unpowered -
IEEE 1394 Port
9. Blocked - IEEE
1394 Port (no
option
installed)
10. PS/2 Mouse &
Keyboard Ports
11. Printer/Parallel
Port
12. Serial Port
13. External Monitor
(CRT) Port
14. Vents
1 - 8 External Locator - Rear View
14
1
14
14
6
2 3 4 5 7 8 10
9
14
14
11
12 13
