Installation; Easy Setup Procedure - Extron electronics Universal Interfaces RGB 130xi User Manual

Controls and Installation, cont'd

Installation

Easy setup procedure

2-7 RGB 130xi xi xi xi xi , 134xi xi xi xi xi , 150xi xi xi xi xi Controls and Installation
Except where noted, the installation procedures for the RGB
130xi, 134xi, and 150xi are the same. See "Cabling" in this
chapter for more information.
If desired, mount the interface to a desk or other
1
suitable surface using Extron's optional mounting
kit. See "Mounting the interface" in the next section.
Turn off power to the computer or workstation and
2
its monitor. Turn off power to the projector or
display device. Disconnect the power cord from the
interface.
Connect the computer to the Analog/ECL* input
3
connector on the front of the interface. If an MBC
interface output cable is being used with the RGB
134xi, connect the MBC cable to the Analog/ECL
connector and connect the MBC power cable to the
MBC power jack. Refer to the diagram in the
"Cabling" section of this chapter.
For the RGB 150xi, if a local computer monitor is
4
being used, connect the monitor to the Buffered Local
Monitor Output connector.
For audio connections, please refer to the following
5
"Cabling" and "Connecting audio output" sections.
Connect the projector or other output display device
6
to the interface's BNC output connectors, as
described in the "Cabling" section.
Set the interface's DIP switches. Refer to the section
7
"Setting the DIP switches" at the end of this chapter.
Power on the computer, monitor, projector/display
8
device, and the interface. The image should now
display on screen. If it does not, double check steps 2
through 7 and make adjustments as needed. To
adjust horizontal and vertical sync polarity and to set
vertical sync pulse width, please refer to the "Setting
internal jumpers" section at the end of this chapter.
* RGB 150xi is analog only
