Specifications — RGB 130xi, 134xi, 150xi

Video input

Number/type .............................. 1 analog RGBHV, RGBS, RGsB,
Connectors .................................... 1 15-pin HD male (150xi)
Nominal level(s) .......................... Analog — 0.3V to 1.5V p-p
Maximum level(s) ....................... Analog — 1.5V p-p
Impedance .................................... 75 ohms or (for 130xi and 134xi) HI
Horizontal frequency ................. Autoscan 15 kHz to 125 kHz
Vertical frequency ....................... Autoscan 30 Hz to 120 Hz
Return loss .................................... -30dB @ 5 MHz
Maximum DC offset ................... 4.0V
Video throughput
Gain ............................................... Unity, 0.725V p-p, 0.750V p-p
Bandwidth .................................... 300 MHz (-3dB)

Video output

Number/type/format ................ 1 (2 if 134xi) analog RGBHV,
Connectors .................................... 6 BNC (2 x 6 if 134xi) female
Nominal level .............................. Unity, 0.725V p-p /50% peaking,
Impedance .................................... 75 ohms
Return loss .................................... -30dB @ 5 MHz
Sync
Input type ..................................... RGBHV TTL (±), RGBS TTL (±),
Output type .................................. RGBHV (±), RGBS(±), RGsB (-)
Input level .................................... 2.0V to 5.5V p-p with ±0.2VDC
Output level ................................. 4.0V to 5.0V p-p
Input impedance ......................... 10 kohms
Output impedance ...................... 75 ohms
Max. propagation delay ............. 48 nS
RGB 130xi xi xi xi xi , 134xi xi xi xi xi , 150xi xi xi xi xi Appendix
A-1
RsGsBs
1 9-pin D male (130xi and 134xi)
Z, switchable - set to 75 ohms if no
local monitor is connected
RGBS, RGsB
1 15-pin HD female localmonitor
(150xi only) output (buffered)
0.750V p-p /100% peaking
RGsB 0.3V (-), RsGsBs 1.3V (-)
offset (max.)
